Recording - JVC RC-EX30B Manuel D'instructions

RECORDING

Basic operation
Standard recording
1 Prepare the recording source.
• When recording from the radio:
Set to the tuner mode and tune in a desired station.
• When recording from a CD:
Set to the CD mode and load a CD.
2 Load a blank or erasable cassette.
Use only a type-I normal tape.
3 Press REC ¶.
PLAY 2 is also depressed, and recording starts.
To stop recording
Press STOP/EJECT §.
The tape also stops when it reaches the end.
Notes:
• It should be noted that it may be unlawful to re-
record pre-recorded tapes, records, or discs without
the consent of the owner of copyright in the sound
or video recording, broadcast or cable program and
in any literary, dramatic, musical, or artistic work
embodied therein.
• The recording level is automatically set correctly, so it
is not affected by VOLUME. Thus, during recording
you can adjust the sound you are actually listening to
without affecting the recording level.
• If a recording you made has excessive noise or static,
the unit may have been too close to a TV which was on
during the recording. Either turn off the TV or increase
the distance between the TV and the unit.
19
1 2 3
PUSH
REMOTE
DISPLAY
SENSOR
Using the beat-cut function
When recording an AM broadcast, beats may occur. If
this happens while recording an AM broadcast, press FM
MODE/BEAT CUT on the remote control unit to select
the better beat-cut setting, "CUT-1" or "CUT-2."
To start recording at the exact moment
1 Press PAUSE 8 first, then press REC ¶, thus
2 Press PAUSE 8 to release the tape at the exact
Note:
Do not leave the unit in pause mode for more than a few
minutes. Instead, press STOP/EJECT § to stop the
tape.
STANDBY/ON
DISPLAY
PRESET EQ
FM MODE
/BEAT CUT
PRESET
DOWN
FM MODE FM MODE
/BEAT CUT /BEAT CUT
entering the record-pause (standby) mode.
moment you want to start recording.
1
CD/ TUNER/
RANDOM BAND TAPE
1 2 3
4 5 6
HBS/
7 8 9
OVER
0
PROGRAM/
+
UP CLOCK SET INTRO
GROUP
REPEAT MUTING
–
VOLUME
RM-SRCEX30J REMOTE CONTROL
