Refer to the manual of your recirculation kit for remov-
ing and putting back the monoblock filter.
Regenerate the Monoblock recirculation filter
• The Monoblock can be regenerated up to 12 times.
This is done in the oven.
• Place the filter in the oven for 1 hour at 120°C. Pro-
vide sufficient fresh air in the room where the oven
has been placed, as smells can be released. Smells
can be released when baking certain kinds of fish.
In this case it is best to immediately regenerate the
filter in the oven.
Reset the Monoblock recirculation filter
The cooker hood (motor) must be running
Simultaneously press + and – for 5 sec. until the red
indicator lamp flashes 3 times for confirmation. If the
programming is not carried out, the programming is
automatically set after the chimney hood has been
switched on 10 times.
After a reset, the cleaning indication will be set to 200
hours.
Place the Monoblock recirculation filter
Refer to the manual of your recirculation kit for remov-
ing and putting back the monoblock filter.

4.3 Maintenance of the hood

Please allow the lights to cool down sufficiently before
cleaning the hood. Use a soft, wet cloth and a mild
detergent to clean the hood. Never use aggressive,
abrasive detergents or sponges. Bleach will damage
stainless steel.
The stainless steel surfaces can be treated with Novy
Inoxcleaner (906.060) after cleaning.

4.4 Led lighting

Replacing the led lighting
First, remove the power supply from the hood and al-
low the lighting to cool down sufficiently.
1. Carefully press the spotlight holder; next, remove
the spotlight holder by means of a tilting movement.
2. Removing the LED lamp:
A. First disconnect the cable to the LED to be replaced.
Disconnect by means of releasing the lock, by ap-
plying light pressure while at the same time pulling
away.
B. Next, remove the LED to be replaced by making a
gentle rotating movement to the left.
3. Mounting the new LED:
A. Place the new LED light into the locking ring.
B. Make a rotating movement to the right until the LED
light is locked.
C. Connect the power cable.
D. Place the spotlight holder back in the cooker hood
and reconnect the power.
Change in colour temperature with LED-lighting
First make sure that the power supply of the hood has
been disconnected. Remove the plug from the hood or
switch off the power group.
The colour of the LED-lighting has been set to 2.700 K
(warm white) by default. If the colour is to be changed
to 4.000 K (neutral white), follow the instruction given
below:
• Open the bottom plate at the bottom of the hood.
• Press with two hands against the side of the inox
lamp holder and carefully pull down simultaneously,
so you get access to the lighting on the inside.
• The wiring has been connected to the LED-lamp
with a connector.
• Disconnect the connector from the LED-lamp and
move the wiring to the other free connection on the
lamp.
