OPERATING INSTRUCTIONS
IMPORTANT: Before operating this appliance, make sure it has been properly installed according to the
appliance's Owner's Manual.
For your convenience, your refrigerator and freezer temperature controls are set to the recommended set
points at the factory. When you first install your refrigerator, make sure the temperature controls are still set
to the recommended set points. The recommended set points are 37°F (3°C) for the refrigerator and 0°F
(-18°C) for the freezer.
The touch activated controls are located above the external dispenser and on
the side of the left inner refrigerator door.
IMPORTANT:
� The recommended settings should be correct for normal household
refrigerator use. The controls are set correctly when milk or juice is as cold
as you like and when ice cream is firm.
NOTE: Areas such as a garage, basement, or porch may have higher
humidity or extreme temperatures. You may need to adjust the temperature
away from the recommended settings to accommodate for these conditions.
� Wait 24 hours for your refrigerator to cool completely before adding food. If
you add food before the refrigerator has cooled completely, your food may
spoil.
NOTE: Adjusting the refrigerator and freezer controls to a colder than
recommended setting will not cool the compartments any faster.
� If the temperature is too warm or too cold in the refrigerator or freezer, first
check the air vents to be sure they are not blocked before adjusting the
controls.
� Wait at least 24 hours between adjustments. Recheck the temperatures
before other adjustments are made.
NOTE: Some models do not have the 2nd Ice Off control.
TEMPERATURE SET POINTS
1. Touch for refrigerator or
NOTE: To view temperature in degrees Celsius, touch and hold the [°F/°C] button for 3 seconds and
the temperature display will change. To return to Fahrenheit, touch and hold the [°F/°C] for 3 seconds
and the temperature display will change.
To activate Temperature mode for Drawer, touch Drawer and toggle through 4 optional temperature
settings: Meats and Fish, Cold Drinks, Deli and Cheese, and Wine. The display will show the
temperature set point of the selected setting for the Drawer.
Recommended Refrigerator Temperature
Fridge set point range: 33°F to 45°F (0°C to 7°C)
When adjusting temperature set points, use the following chart as a guide.
CONDITION:
Refrigerator too cold
Refrigerator too warm
Freezer too cold
Freezer too warm / too little ice
2. Touch to adjust the Refrigerator zone. The display will show the temperature set point of the
selected compartment as shown.
3. When the temperature in is the range of-Freeze Shield, the display will light up. Freeze Shield is
activated at the coldest freezer set point.
MAX COOL
The Max Cool feature assists with periods of high refrigerator use, full grocery loads, or temporarily warm
room temperatures.
� To turn on the Max Cool feature, press the Max Cool button. When the button is pressed, the icon will
blink 3 times and appear on the display screen.
� To manually turn off the Max Cool feature, press the Max Cool button and the display will blink 3 times
and turn off. The Max Cool feature will remain on for 24 hours unless manually turned off. Adjusting the
refrigerator temperature will automatically turn off the Max Cool feature.
NOTE: Setting the freezer to a colder temperature may make some foods, such as ice cream, harder.
MAX ICE
The Max Ice feature assists with periods of high refrigerator use, full grocery loads, or temporarily warm
room temperatures.
� To turn on the Max Ice feature, press the Max Ice button. When the button is pressed, the icon will blink
3 times and appear on the display screen.
� To manually turn off the Max Ice feature, press the Max Ice button and the display will blink 3 times and
turn off. The Max Ice feature will remain on for 24 hours unless manually turned off. Adjusting the
refrigerator temperature will automatically turn off the Max Ice feature.
NOTE: Setting the freezer to a colder temperature may make some foods, such as ice cream, harder.
W11411656B
W11411660B-SP
French Door Bottom Quick Start Guide
for freezer and toggle through temperature set points.
Recommended Freezer Temperature
Freezer set point range: -5°F to 5°F (-21°C to
-15°C)
TEMPERATURE ADJUSTMENT:
Refrigerator setting 1° higher
Refrigerator setting 1° lower
Freezer setting 1° higher
Freezer setting 1° lower
FREEZE SHIELD MODE
This feature minimizes moisture migration from frozen food. This, in turn, reduces the freezer burn
occurrence.
� To turn on the Freeze Shield mode, toggle to the coldest freezer temperature set point. Freeze Shield is
activated at -6°F (-14°C).
� To turn off the Freeze Shield mode, toggle from the coldest freezer set point to any other temperature.
WATER FILTER STATUS
Displays the status of the water filter. To reset the water filter, press Max Ice and Max Cool for 3 seconds.
After countdown, the Good icon will blink 3 times and remain lit.
The water filter status lights will let you know when to replace the water filter. See "Water Filtration System"
in the Owner's Manual.
� Yellow: ORDER—Order a replacement filter.
� Red: REPLACE —Replace the water filter. While you are dispensing water, Replace Filter icon will
flash constantly from beginning to the end of dispensing. After 14 days without replacing the Water
Filter, the Replace Filter icon will blink 7 times and an alert tone will sound 3 times, at the end of
dispensing. See "Water Filtration System" section in the Owner's Manual.
NOTE: "Replace Filter" will remain illuminated if a filter reset is not done.
� RESET FILTER —
Touch Max Cool and Max Ice at the same time on the temperature control display for 3 seconds to
reset water filter. The display will do a 3 second countdown and then flash the icon and play a tone.
ENERGY SAVER
A selectable feature that turns off the heaters around the refrigerator doors and dispenser. When this
feature is enabled, condensation may form on the front of the refrigerator cabinet, gasket, or on top of the
freezer drawer. Savings may vary based on the relative humidity of environment.
� To turn the mullion heater off, press and hold the Energy Saver button for 3 seconds. The Energy Saver
icon will blink 3 times and then remain lit as shown.
IMPORTANT: When Energy Saver is enabled and the LED is on, the dispenser heater and vertical
mullion heater will be turned off.
� Press and hold Energy Saver for 3 seconds again to turn the heaters back on.
POWER OUTAGE
The Power Outage indicator lets you know if the power supply to the refrigerator has been off and the
freezer temperature has risen.
The control panel display will read "Power Outage" and an alert tone will sound 3 times. Touch any button
to stop the tone and turn off the Power Outage icon.
Once the power outage has been confirmed, "Power Outage," will disappear.
SOUND ON/OFF
The Sound button allows the customer to turn the sound on and off.
� To turn on the Sound feature, press the Sound button. When the button is pressed, the Sound icon will
blink 3 times and appear on the display screen.
� To manually turn off the Sound feature, press the Sound button and the display will blink 3 times and
turn off.
SABBATH MODE
Allows the door of the refrigerator or freezer to be opened or closed during the Sabbath or other religious
holidays without activating the interior lights or controls.
The freezer and refrigerator user set points remain unchanged while in this mode. If you unintentionally
turn on Sabbath mode, the word "Sabbath" will light up on the display. Enter and exit Sabbath mode by
pressing and holding °F/°C and SOUND at the same time for 3 seconds.
NOTE: You will be unable to dispense or change temperature set points in Sabbath mode. Your interior
lighting and control panels will all be inactive in Sabbath mode.
SHOWROOM MODE
This mode is used when the refrigerator is on display in a retail store or if you want to turn the cooling off
and deactivates all other functions except interior lighting. Showroom mode can be used when going on
vacation, see "Vacation and Moving Care" section for proper steps on leaving your refrigerator in this mode
for long periods of time.
If you turn on Showroom mode, the word "Showroom" will light up on the display. Enter or Exit Showroom
mode by pressing and holding °F/°C and Drawer at the same time for 3 seconds.
NOTE: Empty ice maker if refrigerator is going to be turned off for an extended period of time.
Online Ordering Information
For detailed installation instruction and maintenance information, winter storage, and transportation tips,
please see the Owner's Manual included with your appliance.
For information on any of the following items, a full cycle guide, warranty, detailed product dimensions, or
for complete instructions for use and installation, please visit https://www.whirlpool.com/owners, or in
Canada https://www.whirlpool.ca/owners. This may save you the cost of a service call. However, if you
need to contact us, use the information listed below for the appropriate region.
United States:
1–800–253–1301
Whirlpool Brand Home Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022–2692
SAVE THESE INSTRUCTIONS
Canada:
1–800–807–6777
Whirlpool Brand Home Appliances
Customer eXperience Centre
200–6750 Century Ave.
Mississauga, Ontario L5N 0B7
