The range

Fuego SCS basic
Fuego SCS basic RF
• [Fuego basic] Tethered foot pedal (R7)
[Fuego basic RF] Radio frequency foot pedal (battery operated) (R8)
• 3 standard-programs for button (function knob) and foot pedal
• SCS (Safety Control System)
• BHC (Burner Head Control)
• Removable and decomposable burner head
• Tilt mechanism, right / left (R1)
• Holding device for 3 inoculation loop holders (11)
• Nozzles for natural gas, propane/butane gas
• Turbo flame
• Wrench 17 mm (R2) for gas connection
• Screwdriver (R3) for burner head and cover of the burner shaft
• Tubing connector with swivel nut for 10 mm pipe spout tubing (R4)
• Power connection with 4 adapter (R5), global (level 6)
• [Fuego basic RF] 2 Mignon batteries (AA),
compartment of the foot pedal (R8)
• Instruction manual
• 2-year warranty
R4
Fig. G
24
Art.-No. 8.201.000
Art.-No. 8.203.000-RF
R5
11
R1
(only available in Europe)
(R6),
already inserted in the battery
R5
R3
R2
R6
R7 R8
