Event programmed with call from main PE 1 to user 01 053.
All calls from main calling station 1 to any real user will activate the decoder.
• Position C: call from any secondary calling station in column number "Column ID" to any user in column
number "Column ID" will activate the decoder.
EXAMPLE
Event programmed for secondary calling station 0 in column 5 to user 024.
All calls from secondary calling station 0 or 1 in column 5 to any real user in column 5 will activate the
decoder.
• Position S: call from any calling station (main or secondary) to a particular real user in the system will
activate the decoder.
EXAMPLE
Event programmed with call from main calling station 3 to user 07 036.
All calls from main or secondary calling station in column 7 towards the real user 07 036 activates the
decoder.
Stored event type
Call from MDU (clearly
defined) to any AS
Call from SDU (on column
C) to any AS (belonging to
column C)
Call from MDU to any AS
(clearly defined)
Call from SDU (belonging
to column C) to AS (well
defined)
Legenda
Q: any device in the system
C: all devices in the respective column
S: only the device used for event acquisition
OPERATING MODE TO SIGNAL PANIC ALARM TO SWITCHBOARD (DIP1 = ON)
This function can be used only in systems with Digital Relay Unit installed in the column and a
concierge switchboard equipped with version 3.1 or higher software.
In this operating mode the Digital Relay Unit must be programmed as follows:
1 – Move the dip-switch 1 in position ON
2 – Assign to the Digital Relay Unit a user code from 0 to 127 using dip-switches CODE
To set the desired code use dip-switches from 2 to 8 (2 = most significant bit – 8 = least significant
bit).
The user code can be the same used in apartment stations of the same apartment.
16
Summary table
Q
Relay switches to activate
the decoder
Relay switches to activate
the decoder only if the main
calling station is the one on
which the event is stored
Respective area jumper position
C
Relay switches to activate
the decoder
Relay switches to activate
the decoder only if the called
apartment station belongs to
column C
MDU: main door unit
SDU: secondary door unit
AS:
apartment station
S
Relay switches to activate
the decoder only if the called
apartment station is the one
on which the event is stored
Relay switches to activate
the decoder only if the called
apartment station is the one
on which the event is stored
Relay switches to activate
the decoder
Relay switches to activate
the decoder
