INSTALLATION AND ASSEMBLY OF THE APPLIANCE
Care must be taken so that the appliance will be in an
upright position at least 2 hours before its first activation.
CAUTION! Correct connection of the device to the single
socket with earth is the guarantee of
proper work. In the case of inappropriate installation, the
machine may cause injury.
Place the appliance on a flat, stable surface that will
withstand its weight together with its contents.
In order to provide adequate ventilation, keep at least 20
cm of space between the appliance and the wall or other
objects.
First start up.
1. Unpack the whole appliance.
2. Make sure that no packing material has been left in
the compressor chamber.
3. Remove all documents and other accessories from
the inside of the appliance.
4. Install all additional components of the appliance.
5. Level the appliance.
6. Clean and dry the interior.
7. Close the cover / door of the appliance.
8. Connect the appliance plug to the socket.
9. Set the cooling power to the maximum.
10. Do not open the appliance for about 4-6 hours or
until the red light (Running) is off.
11. Insert frozen products into the freezer
12. If you need to freeze fresh food, it is necessary
to follow the instructions for freezing fresh food
contained in this document.
Do not store any glass bottles with liquids, because
they increase their volume during freezing and may be
damaged. Never store explosive substances in the freezer.
Height adjustment / levelling:
In order to adjust the height or level of the freezer, it is
necessary to unscrew or screw in the feet of the appliance.
Assembly of the lock (not applicable to RCFZ-W88L):
1. Remove the tape covering the screw holes for the
catch.
2. Position the catch in the correct mounting position.
13. 3. Screw the catch with two screws.
The handle assembly (not applicable to RCFZ-W88L):
1. Fix the handle on the door with 4 screws.
2. Insert the handle cover beginning from one side and
ending on the other side.
3. Push the cover into the holder.
The appliance is equipped with a lock which enables to
protect the freezer against opening (key in the set).
Height adjustment of shelves (RCFZ-W88L only):
1. Remove the shelf.
2. Remove the shelf support and set it to the desired
height.
3. Set the remaining supports.
4. Slide the shelf onto the support.
FREEZING OF FRESH FOOD
1. Place the packaged fresh food in the freezer, paying
attention so that it will not come in direct contact with
already frozen products because they may defrost
and shorten their shelf-life. It is recommended that
fresh food will be placed near the wall or bottom of
the freezer, in these places it is the coldest. Do not
exceed the allowed freezer food quantity for a given
appliance (X kg / 24h).
12
Check this value in the technical data of the appliance
or on the rating plate.
2. Set the cooling power to the maximum.
3. After 24 hours it is necessary to change the location
of the frozen food so that it will be possible to freeze
other products.
4. Set the cooling power which will be appropriate for
filling of the freezer.
5. It is possible to check the temperature inside the
appliance, for example with a thermometer which
scale allows to measure temperatures lower than –
20°C. The temperature of food storage in the freezer
should be at least – 18°C.
SWITCHING ON THE APPLIANCE
1. Close the appliance door.
2. Connect the appliance plug to the power supply. The
appliance will start normal operation and the power
light will switch on but the cooling will start only
after setting a cooling power other than 0. (Setting
cooling power to 0 stops the cooling process, but it
does not turn off the appliance).
DESCRIPTION OF THE CONTROL PANEL
RCFZ-W88L
1 2
1. Adjustment knob of cooling power. 0 means no
cooling (in order to set the right temperature using
the adjustment knob, it is recommended to use a flat
tool, for example, a screwdriver).
2. Light switch.
RCFZ-98, RCFZ-152, RCFZ-197, RCFZ-252,
RCFZ-560, RCFZ-459, RCFZ-368
1 2 3
1. Green signal light (Power Indicator – signals power
supply connection and that the appliance is switched
on.
2. Red signal light (Running) – Indicates that the
interior temperature is higher than the set target
temperature. It is usually switched on in case of:
• The first start up of the appliance
• Start after defrosting
• Filling the freezer with fresh products
3. Cooling power adjustment knob (0 – no cooling; 1
– light cooling; 7 – maximum cooling power)
Rev. 23.11.2017
SELECTION OF TEMPERATURE SETTINGS
In order to turn on: turn the temperature adjustment knob
on the right to the level (other than 0) which is required:
• minimum (light cooling)
• maximum (lowest temperature)
The temperature should be set depending on:
• ambient temperature
• quantity of stored food
• opening frequency
MAXIMUM FILLING HEIGHT OF THE FREEZER
Never fill the freezer until the edge being in contact with
the cover. Always keep the distance between the cover and
the frozen products.
Set the temperature adjustment knob depending on the
filling of the freezer.
DEFROSTING
Under normal conditions of use (3-4 openings per day), the
freezer should be defrosted once or twice a year (in case
of more frequent opening the freezer should be defrosted
more often).
The appliance must be defrosted especially when the
thickness of the ice layer on its walls will be about 5-7 mm.
Ice layers on the internal walls of the appliance reduce its
efficiency.
Layers of ice can be scraped with a plastic scraper. Do not
use metal things to scrap ice from the appliance.
Warning! Never use electrical appliances to defrost freezers
(e.g. hair dryer) or open flames (e.g. candles). The plastic
parts of the interior can melt and the emanate vapours can
inflame through sparks or a flame.
In order to defrost it is necessary to proceed as follows:
1. Make sure the appliance plug is removed from the
socket.
2. It is recommended to use a plastic bowl or other
sealed container to collect leaking water in the
course of defrosting.
3. Make sure that the hands are dry in the course of
performing subsequent activities in order to avoid
damages caused by a negative temperature (use of
gloves is recommended).
4. Remove the frozen products and make sure that the
water melting from them will not cause any danger
or damages. It is recommended to place them in
a sealed container.
5. (Not applicable to RCFZ-W88L) Using a flat tool,
lever up and remove the stopper from the bottom of
the freezer.
6. (Not applicable to RCFZ-W88L) Pull out manually the
plug located in the front bottom part of the freezer,
provide a suitable container for the water flowing
out.
7. It is recommended to scrape the thickest layers of
ice.
8. If necessary, defrosting can be accelerated by
inserting a dish with warm water dish (not boiling or
hot!) into the freezer.
9. Wait until the ice from the inside of the freezer is
melted, in the course of defrosting it is possible to
remove the water from the inside of the freezer with
a sponge.
11. Before using the appliance again, clean the inside of
the appliance.
Rev. 23.11.2017
12. Plug the holes (on the bottom of the freezer and in
its front bottom part) with stoppers.
13. Close the cover / door and connect the appliance to
the power supply.
14. Set the cooling power to the maximum.
15. Insert products to be frozen into the freezer.
16. After about 4-6 hours or when the red light
("Running", except the model RCFZ-W88L) turns off,
set the cooling power appropriately to the filling of
the freezer.
INTERIOR LIGHTING
For RCFZ-98, RCFZ-152, RCFZ-197, RCFZ-252, RCFZ-560,
RCFZ-459, RCFZ-368
When the freezer cover is open, the internal lighting of the
appliance automatically lights up automatically. When the
freezer cover is closed, the interior lighting of the appliance
goes out.
In the model RCFZ-W88, it is necessary to turn on the
lighting individually, depending on the needs.
EXCHANGE OF INTERNAL LAMP
Replacement or repair of the lamp should be made by
a qualified specialist.
Before replacing the lamp and any maintenance work, it
is necessary to disconnect the plug of the appliance from
the socket.
The lamp is located behind the transparent shield on the
cover of the appliance or – in case of the model RCFZ-W88L
– on the top wall of the appliance.
If you need to replace the lamp, remove the cover screws,
remove the cover, replace the lamp with a new one with
the same parameters and then reinstall the cover with the
screws.
TRANSPORTATION AND STORAGE
During transport, the machine should be protected from
shaking, falling and turning upside down. Store it in
a properly ventilated place with dry air and without any
corrosive gas.

CLEANING AND MAINTENANCE

It is recommended to wash the freezer regularly.
Before start of cleaning of the appliance or before
performance of any repair or maintenance work, it is
necessary to disconnect the appliance from the power
supply and wait until it has cooled down.
Do not use for washing any caustic cleaners, such as
cleaning powders, agents with alcohol content, thinners,
diluents, etc., and do not allow water to enter the freezer
interior. Never immerse the appliance, cord or plug in water
or any other liquid. It is forbidden to clean the device with
a water jet. The interior of the device should be cleaned
with a disinfectant suitable for the food industry. To clean,
use a damp, soft cloth and then dry thoroughly. Dry the
surface with a soft, dry cloth. The following actions should
be taken if the machine is not used for a long period of
time: Disconnect the appliance completely from the power
supply and remove all food products from it. Then wash the
entire appliance with a damp, soft cloth and mild cleaning
agent, rinse with clean water and dry thoroughly, for some
time leave the door open, so that the appliance will be
completely dry. From time to time, check that the cable
is not damaged. Do not use the appliance if the cable is
damaged. A damaged cable must be replaced by a service
or a qualified electrician.
