TOP SURFACE INSTALLATION
NOTE:
• C5-FF27-X and C5-FF31-X MODELS ONLY: For accessories related to the top surface, please
read those instructions thoroughly before proceeding with the following installation.
• To help protect the wood finish from scratching, do not place any components or tools on
unprotected wood surface during assembly. For wood kit care and cleaning, refer to I-00788.
1. Align the top using wooden dowels (where applicable) in the side panels as a guide.
2. Attach top surface to the frame using provided wood screws (HW Kit #91-00517), extra screws
provided. (FIGURE C)
Number of #10 x 5/8" Screws Used Per Credenza Top
Configuration
3-Bay
2-Bay
1-Bay
FIGURE C
Screws
12
8
4
Page 8
