ION Raptor Guide D'utilisation Rapide page 5

Features
Front Panel
11
12 10
10
1. Power Button: Turns Raptor on or off. Please note that while Raptor is connected to a
power source, it does not need to be powered on to charge the battery. When the power is
on, the display will show the power indicator.
2. Bluetooth Button: Press the Bluetooth button to disconnect a paired Bluetooth device
and enter pairing mode to connect to another Bluetooth device.
3. Light Mode Button: Press this button to select how the lights on the front panel function:
•
White: The lights are lit solidly white.
•
Color Cycle: The lights slowly glow and cycle through colors. Press and hold the light
mode button to freeze the lights on one color.
•
Beat Sync: The lights react to the beat of the music.
•
Off: The lights turn off. This is the default mode when Raptor is first powered on.
4. Radio Selector: This button sets the Radio to AM, FM, or turns the radio off.
5. AM/FM Presets: Store a favorite radio station and quickly tune to a preset radio station.
There are 6 numeric positions to store AM band presets and 6 numeric positions to store
FM band presets. To add a preset:
i. Select either the AM or FM band and then use the Tune/Track Buttons to select the
desired radio station.
ii. Press and hold a numeric preset button to assign the current station to that preset
number. The display will show "SAVE" to show the station has been saved. To use an
added preset, tap a preset number once lightly to go to the stored radio station.
6. Tune/Track Buttons: Tap these buttons to tune in a radio station or go to the previous/
next track on a Bluetooth connected device. To "seek" (jump to the next clear station),
hold either button down for a few seconds until it starts to seek a station. The unit will
remember the last station it was on and start at that station when powered off and on
again.
7. Play/Pause: Press to play or pause a track from a connected Bluetooth device.
1
2
3
4
8
5
13
6
7
9
5
