GE RAK4002D Instructions D'installation

Before you begin - Read these instructions completely and carefully.
IMPORTANT – OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer – Be sure to leave these instructions with the Consumer.
Note to Consumer – Keep these instructions with your Owner's Manual for future reference.
Tools Needed
• 5/16" Nut Driver
• 1/4" Nut Driver
Important Notes
• This unit must be properly grounded.
• Connections are made inside this junction box
assembly.
• This kit provides for connection of 1/2" trade
size electrical conduit and connection to a
wiring system in accordance with the National
Electric Code. ANSI/NFPA No. 70-2014. It
also provides for use with optional sub-base
and chaseway RAK204U, RAK204D15*,
RAK204D20*, RAK204D30*, (replacement
parts: RAK204E15*, RAK204E20*, and
RAK204E30*).
• This kit contains 1 junction box for use with
molded plastic control board covers found on
AZ45/AZ65 series models ending in W5 or
higher.
* All Series
Parts Included
• 1 Junction box assemblies
• Mounting screws (3)
• Wire retaining clip
Installation Instructions
for your new
RAK4002D
Junction Box Kit
For AZ45/AZ65 Series Zoneline
WARNING
RISK OF ELECTRIC SHOCK.
Disconnect the electrical power supply before
wiring connections.
INSTALLATION NOTES
Reference Installation Instructions in the Zoneline
Owner's Manual.
A. Branch Circuit Connection 230/208 volt
To connect branch circuit to unit using direct
wiring, use properly rated wire nuts and
enclose fully within junction box.
B. For use with sub-base and chaseway
Branch circuit wires can be run from the sub-
base, up the chaseway and into the junction
box where connections are made. Electrical
connections can be made directly to the
branch circuit with properly rated wire nuts
or by plug through receptacle of appropriate
sub-base. See additional Installation
Instructions with the sub-base kit.
Power supply kits or unit cords can be run
from the junction box, down the chaseway
and into the sub-base.
31-5000335 Rev. 1 07-21 GEA
