MACHINE OPERATION (SCRUBBING/DRYING)

1. Start the machine as shown in the previous paragraph.
2. If necessary, press the washing water fl ow control switches (82) as necessary, depending on the type of cleaning to be carried
out.
3. If necessary, stop the machine and turn the squeegee adjusting handwheel (27) and adjust the squeegee so that the rear
blade (25) touches the fl oor in all its length.
Machine drive controls
CAUTION!
This procedures must be performed by qualifi ed personnel or KENT personnel.
The machine speed and forward movement capability depends on the fl oor type and on the choice of using brush or pad.
These can be adjusted by two screws (B and D, Fig.18), which are on the brush plate, according to the following procedure:
– When turning the adjusting handwheel (28) counter-clockwise, the machine moves towards the left; when turning it clockwise
the machine moves towards the right;
– (only for RAZOR 20) When turning the adjusting handwheel (29) counter-clockwise, the machine speed increases; when
turning it clockwise the machine speed decreases.
NOTE
For correct scrubbing/drying of fl oors at the sides of the walls, KENT suggests to go near the walls with the right side of
the machine as shown in fi gure 3.
CAUTION!
To avoid any damage to the fl oor surface, turn off the brush/pad-holder when the machine stops in one place,
especially when the extra pressure function (optional) is on.
Working with brush/pad-holder extra pressure function activated
If the fl oor proves to be particularly diffi cult to clean, it is possible to turn on the brush/pad-holder extra pressure function by
pressing the pedal (11) to position (11c).
Battery discharge during operation
Until the green warning light (81a) stays on, the batteries allow the machine to work normally.
When the green warning light (81a) turns off, and the yellow warning light (81b) turns on, it is advisable to charge the batteries,
because the residual autonomy will last for a few minutes (depending on battery characteristics and work to be performed).
When the red warning light (81c) turns on, the autonomy is over. After a few seconds, the brushes/pad-holders are
automatically tuned off, while the vacuum system and (only for RAZOR 20T) the drive system stay on, to fi nish drying the fl oor
and drive the machine to the appointed recharging area.
CAUTION!
Do not use the machine with discharged batteries, to avoid damaging the batteries and reducing the battery life.
A
RAZOR 20 - RAZOR 20T
INSTRUCTIONS FOR USE
Figure 3
