Sony PS3 Guide De Démarrage Rapide

Getting Started
System front
USB connectors (open) button
System storage access indicator Disc cover
Power button/Power indicator
Solid green: System on
Flashing green: System turning off
Solid red: System off (in standby mode)
Connection and Setup
AV MULTI OUT connector
AV cable
to the TV video input connector
Connect your PS3 system to a TV.
TM
For high definition output, connect the TV and the PS3
Turn on the TV and then select the appropriate input.
Press the power button to turn on the PS3
If video is not displayed, turn off the PS3
for at least five seconds (until the system beeps a second time).
Press the PS button on the wireless controller.
Follow the on-screen instructions to perform the initial setup.
Connect to the network
Connect using a wired connection
To the Internet line
Network gateway device
such as a DSL modem
Connect an Ethernet cable (sold separately) to the PS3
Select (Settings) (Network Settings)
Select [Easy].
Check that the settings are correct, and then save the settings.
Using PlayStation Network
®
Playstation Network is the service to use for online gaming,
®
online shopping at (PlayStation
under (Friends) and access to other online services. To
create a Sony Entertainment Network account, select
Up) under (PlayStation Network), and then follow the
®
on-screen instructions.
Supporting documentation
Safety and Support
This document contains information about how to safely use the PS3
terms. Be sure to read it before using the PS3
Online user's guide manuals.playstation.net/document/
This guide contains detailed information about using the PS3
You can also view the guide on your PS3 system under
TM
System software updates us.playstation.com/ps3
This site provides the latest information about system software updates.
Support Knowledge Center us.playstation.com/support
The official site for PlayStation product support provides the latest questions and answers about your product.
®
Design and specifications are subject to change without notice.
" ", "PlayStation", " " and "DUALSHOCK" are registered trademarks of Sony Computer Entertainment Inc.
" " is a trademark of the same company.
"XMB" and "xross media bar" are trademarks of Sony Corporation and Sony Computer Entertainment Inc.
"SONY" and " " are registered trademarks of Sony Corporation. "Sony Entertainment Network" is a trademark of the same company.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.
©2012 Sony Computer Entertainment Inc. All rights reserved.
System rear
LAN connector
HDMI OUT connector
DIGITAL OUT (OPTICAL) connector
AV MULTI OUT connector
USB connector
USB cable
AC IN connector
to the outlet
AC power cord
system using an HDMI cable (sold separately).
TM TM
system.
TM
system, and then turn it on again by pressing the power button
TM
Ethernet cable
Router
system.
TM
[Internet Connection Settings].
Store), joining in a chat
®
(Sign
system. It also contains product warranty
TM
TM system.
system.
TM
(Network) (Online Instruction Manuals).
Printed in China
Port indicators
L1 button L2 button
Directional buttons
AC IN connector
Left stick/L3 button*
SELECT button
Playing disc content
to the USB
connector
Insert the disc with the label side facing up.
Open the disc cover and insert the disc.
To open the disc cover, you can either press the
Push the disc into place until you hear a click.
Slide the disc cover closed.
When you close the disc cover, the disc will automatically start playing. If the disc does not automatically start,
select the icon for the disc from the XMB
・To quit a game, press the PS button on the controller and then select
To quit playing other types of discs, press the
・Saved data for PlayStation
To display the data, go to
Connect wirelessly
To the Internet line
Network gateway device
such as a DSL modem
Select (Settings)
Select [Easy] [Wireless]
Select the access point you want to use.
Check that the SSID is correct, and then
press the right button (directional buttons).
Select the type of encryption key.
Enter the encryption key.
Press the button to display the keyboard.
Enter the encryption key and then select [Enter].
Check that the settings are correct,
and then save the settings.
DUALSHOCK 3 wireless controller
®
PS button: Displays the XMB menu
TM
Turns the system on/off
Quits a game
XMB (XrossMediaBar) menu
TM
(open) button or manually slide the disc cover to the left.
menu, and then press the button.
TM
(Quit Game).
button on the controller.
3 format software is saved in hard disk.
®
(Game) (Saved Data Utility(PS3 )).
TM
Wireless router
(access point)
(Network Settings) [Internet Connection Settings].
[Scan].
Switches
between upper
and lower case
USB connector
R1 button R2 button
button: Displays the options
menu/control panel
button: Confirm the selected
item
button: Cancel an operation
Right stick/R3 button*
START button
* The L3 and R3 buttons function
when the sticks are pressed.
Category
Delete Enter typed
characters and exit
the keyboard
Quick start guide
CECH-4001C 4-431-011-41(1)
