Minilux Sensor PIR 360° Wireless 41-380
Fitting and operating instructions
General:
The Minilux Sensor PIR 360° 41-380 is a movement
sensor based on wireless technology that sends an
RF telegram to a receiver module, which switches
the light on and off.
1st priority: Daylight
2nd priority: Movement
·
Areas of application:
·
Small offices
·
Open-plan offices divided into workgroups
·
Premises with rest areas
·
Shared activity rooms
·
Changing rooms
·
Large storage rooms
Function:
The integrated light sensor measures the light level
in the area continuously, and compares it with the
preset value specified via the LUX setting button.
If the light level falls below the preset value and the
movement sensor detects activity in the coverage area,
the light is switched on. The integrated cut-out delay of
1...30 mins (adjustable) makes sure that RF switch-on
telegrams are sent continuously (approx. once a
minute) to the receiver, until the sensor does not
register activity or the selected light level is reached.
1
Coverage area:
The movement sensor is designed to be fitted to a
ceiling. At a height of 2.5 metres the sensor will cover
a floor area with a diameter of 20 m and provide full
360° coverage for movement of people. The sensor
has a special lens area in the centre with a diameter
of 5 metres, with more than 618 fields guaranteeing
optimal detection of even very slight movements.
The movement sensor is designed to be fitted to a
ceiling at a standard height of 2.5 - 3.0 m, and is
positioned over a desk, typically 1 m away from the
seat. The sensor has a specially developed optical
function with two detection ranges, a close range (A
+ B) to detect small movements and a distant range
(C + D) to detect movement of people. This
combination provides excellent control of lighting,
while at the same time guaranteeing the best
possible energy saving.
2
Limiting the detection range:
If the coverage area is too large, it can be limited by
fitting the enclosed cover. This enables the maximum
range of 20 metres to be reduced to 12 metres, 5
metres or 3 metres in radius, and the angle of 360°
can be reduced in increments of 45°.
3
Caution!:
It is recommended that the PIR Sensor is not
installed where it is exposed to direct sunlight, air
flows from air conditioning, radiators, etc. With a view
to achieving optimal transmission of the RF signal to
the receiver, the PIR Sensor should not be fitted to
premises with metal screening, which blocks signals
between transmitter and receiver, please see the
section on RF wireless information.
4
Installation:
a) The ideal measurement of daylight is obtained by
positioning the movement sensor with the light
sensor facing the source of daylight.
b) If the movement sensor is fitted directly to the
ceiling, holes at intervals of 105 mm can be
used. Please note that the cable input is turned
45° in relation to the fixing holes.
c) If the movement sensor is fitted to a ceiling box, the
holes located for this purpose at intervals of 60 mm
are used, and the base opening is punched out.
d) Neverfit the movement sensor to a metal panel,
as this reduces the RF signal dramatically.
5
Connection:
a) First read the WHOLE installation and user manual.
b) Switch off all power during installation and setup.
c) Note that the movement sensor can be connected
to EITHER 230Vac OR 24Vac/DC.
d) All assembly/cable laying must be undertaken
correctly in accordance with the prevailing
Installation Regulations.
e) 230Vac is connected via the terminals labelled:
L, N and the protective conductor to
f) 24VDC or ac is connected via the terminals
labelled: -24V and +24V.
g) Power up causes an RF switch-on telegram to be-
sent. The integrated indicator LED1 red or LED2
green will always be lit for 1 minute (stabilisation time).
6 Connection chart:
A 230Vac or a 24Vac/DC power supply is one option.
This means that both may not be connected.
7 Setting up/testing:
The movement sensor is supplied with two test mode
functions, one for a LUX test a) and for a PIR test b).
The chosen function is indicated with 2 LEDs, LED1
red for 1st priority: daylight or LED2 green to indicate
PIR activity, as the only priority. LED1 and 2 –
indication c). PIR sensitivity setting d) can be set in
4 different sensitivity positions.
LRN button is a wireless system coding for the
receiver, LED3 yellow indicates RF signal.
By the means of the LUX setting daylight blocking
can be deselected.
LED1 red indicates 1st priority: daylight and PIR
activation (Light + Movement).
LED2 green indicates the only priority is movement
and PIR activation (Movement).
LED3 yellow indicates that the RF signal is being
transmitted to the receiver.
a) LUX TEST mode.
Set the switches to DIP1 ON and DIP2 ON.
In this position an RF switch off telegram is transmitted
to the receiver module. Turn the LUX setting slowly
from min. towards max. until the integrated indicator
LED1 red lights up. At this point the LUX setting is
identical to the daylight level measured by the sensor. If
the daylight level in the room is sufficient, turn the LUX
setting towards minimum until the LED is switched off,
and leave the LUX setting at this level.
If the LUX setting is turned towards min., the lighting is
switched off at a lower daylight level.
If the LUX setting is turned towards max., the lighting is
switched off at a higher daylight level.
Finish by setting the switches to DIP1 OFF and DIP2 OFF.
b) PIR TEST mode.
Set the switches to DIP1 OFF and DIP2 ON.
In this position an RF switch-on telegram is transmitted
immediately upon PIR activation and an RF switch-off
.
telegram after 5 seconds, if there is no new activation.
PIR activation is indicated via the integrated indicator
LED1 red or LED2 green.
PS: In this test the daylight blocking will not be working.
Finish by setting the switches to DIP1 OFF and DIP2 OFF.
c) LED1 and 2 – indication on.
Set the switches to DIP1 ON and DIP2 OFF.
In this position LED1 red will indicate PIR activity and
that daylight blocking is selected; the PIR timer
setting is adjustable from 1-30 mins. If daylight
blocking is deselected (LUX setting at off position)
LED2 green will indicate PIR activity; the PIR timer
setting is adjustable from 10 sec....30 mins.
We recommend that LED1 and 2 are switched off, by
setting DIP1 and 2 to OFF, so that people do not feel
that they are being watched.
d) PIR sensitivity setting
Switches DIP3 and DIP4 enable you to customise
the sensor's sensitivity. In the factory the product is
set to high sensitivity. The options are described in
fig. 7 .
LRN button.
If you press this button (learn), an RF status telegram
will immediately be sent to the receiver, indicated via
LED3 yellow. Must be used for system recognition of
the receiver.
PS: The receiver must also be set to "Learn mode";
please refer to the receiver's description of the
learning method.
The PIR Sensor is preset in the factory as follows:
• Sensor on automatic, with daylight blocking.
• LED1 and 2 switched off.
• High sensitivity.
Deselection of daylight blocking.
If the LUX setting is turned towards max. to the OFF
position, the PIR Sensor will operate without daylight
blocking. In this position the PIR timer setting can be
adjusted to 10 sec....30 mins.
8 Assembling the sensor:
a) Press the sensor part up into the terminal array in
the base, and fit the Pozidrive (PZ)0/Philips (PH)
locking screw.
b) Set and test the sensor as described in fig. 7 .
c) Reduce the coverage area as described in fig. 2 .
d) Fit the Sensor's cover.
