Model : OLB64R200LB-5MC & OLR160B20C
ITEM PART #
1 B30786-02 Complete heat exchanger (combustion chamber included)
2 B30596 Top heat exchanger
3 B30531 Combustion chamber (item 7 included)
4 F07O001 Hexagonal flange nut 3/8-16NC brass
5 B30753 Gasket panel, peep hole
6 B30787 Bottom heat exchanger
7 B30532 Gasket, heat exchanger
8 B30534 Gasket, heat exchanger
9 B30415-02 Gasket, heat exchanger
10 B30665 Front baffle
11 B30664 Rear baffle
12 B30666 Divider panel
13 B30669 Plenum divider
14 B30481 Blow er baffle
15 B30663 Floor
16 B30680-02 Left side panel assembly
17 B30686-02 Left side panel insulation
18 B30668-02 Left bottom filter support
19 B30667 Left top filter support
20 B10256-99 Tab
21 B01291-02 Gasket, seal strip
22 B30683 Blow er door assembly (labels included)
23 B30678 Air filter draw er
24 B30836 Top rear panel
25 B30589-01 Gasket, breech plate
26A B30646 6" breech plate (chimney application)
26B B30647 4" breech plate (direct vent application)
27 F07O001 Hexagonal flange nut 3/8-16NC brass
28 J06L002 Seal strip 1/2" x 1/8" x 25'
29 B30680-05 Right side panel assembly
30 B30686-01 Right side panel insulation
31 B30668-01 Right bottom filter support
32 B30835 Right top filter support
33 B30782-01 Front panel assembly (labels included)
34 B30780 Front panel insulation
35 B30752 Washer, peep hole
36 F06F005 Washer 3/8" AA zinc
37 F07F024 Hexagonal nut 3/8-16NC brass
38 Z04F007 Paper filter 16 x 24 x 1
39 B30676 Flange plate
40 F07O001 Hexagonal flange nut 3/8-16NC brass
41 B30486 Access cover
42 B40085-01 Electrical box cover (w ithout logo)
43 L05F011 Terminal strip, 6 positions
44 L07F016 Rocker sw itch SPST (main pow er)
45 L07F003 Rocker sw itch SPST (constant blow er operation)
46 B30828 Electrical box (box only)
47 R02I005 Fan Limit Control 8"
48 L01F009 Transformer 120/24 VAC / 40 VA
49 A00336 Terminal strip, 6 positions
50 L01H009 Relay SPDT 24VAC
51 Z01F006 Rubber grommet.
52 B01756 Blow er support bracket
53 B30530-01 Blow er electrical kit
54 L04I010 Strain release bushing
55 B01024 Capacitor holder
56 L01I005 Capacitor 15 MF
57 Z01L003 Blow er w eel G12-10DD
58A Z01I008 Blow er GT12-10DD (housing and w heel)
58B B01406-06 Blow er assembly (items 55, 56, 58 and 60 included)
59 B01889 Motor mount assembly (legs, band and screw s)
60 L06I004 3/4 HP direct drive motor (w ithout legs)
61A K30011 Peep hole kit
61B K30012 Overfire pressure test kit
62 B30055 Gasket, glass
63 B30041-01 Glass, neoceram
64 Z06G001 Blocked vent shut off BVSO
PARTS LIST
DESCRIPTION
33
