Unpacking
1 Remove packing materials from unit.
Note: Save all packing materials.
2 Remove plastic bag covering radio.
3 Remove AC ADAPTER from packing.
4 Remove tie from A/C ADAPTER.
5 Open lid and remove styrofoam shipping material from turntable.
6 Remove black tie-wrap from under the tone arm.
7 Remove white protective needle cover by gently
pulling towards the front of the unit.
8 Turn the TURNTABLE SUSPENSION SCREW
clockwise until it is all the way down.Do not force
or over tighten it. This allows the
turntable to float on its shock absorbers.
9 Release tone arm hold down clip by gently
pushing to the right. This will unlock tone arm
from its arm rest. Re-lock the hold down clip
when moving the unit to another location.
Power Source
1 Untie the tie-wrap on the AC ADAPTER .
2 Plug the AC ADAPTER into appropriate wall outlet.
3 Plug the small end of the adapter into the DC JACK on the back of the unit.
Radio Operation
1 Set the FUNCTION SWITCH to RADIO mode.
2 Set the AM / FM SWITCH to the desired Band.
3 Select the desired radio station by rotating TUNING KNOB .
4 Adjust the VOLUME ON/OFF KNOB to the desired sound level.
Headphone Jack Operation
1 Connect the headphone to the HEADPHONE JACK.
2 Adjust volume to the desired listening level.
NOTE: * When using headphones, the sound to the unit speakers will be cut off.
* Headphones not included with unit.
Turntable Operation
1 Turn the ON/OFF VOLUME KNOB clockwise to turn the unit on.
2 Set the SPEED CONTROL SWITCH to to the correct speed (33 1/3,45 or 78 rpm).
3 Place the record on the turntable.
4 Use the CUE LEVER to raise the tone arm off its rest. Move the tone arm over the record and use the
cue lever to lower it onto the record. The record will begin to turn automatically.
5 At the end of the record, the tone arm will return to its rest.
Accessory:ADAPTER FOR 45 RPM
This adaptor allows you to play 45 RPM records.
1 Place the 45 RPM adaptor over the spindle.
2 Gently place your 45 RPM record onto the turntable.
3 Follow the steps under turntable operation to play your record.
LINE Outputs
1 You can connect your turntable to external stereo systems using the RCA style LINE OUT jack.
2 To use this feature, connect RCA stereo cable
turntable, connect the other end of the cable to the input of your external stereo system. For specific
information on how to hook into your external stereo system, please see the instruction
particular device.
Troubleshooting
The unit does not operate.
1 Make sure the AC POWER CORD is connected to an AC outlet and the back of the unit.
2 The unit is not turned on : turn the VOLUME
knob from the OFF position.
No sound comes from unit
1 The white protective needle cover was not removed.
2 The volume is too low.
Tone arm does not move
1 Black tie-wrap was not removed from tone arm.
2 Tone arm hold down clip was not released.
(not supplied) to the LINE OUT jack on the back of the
manual for that
