SPX RADIODETECTION RD7100 Guide D'utilisation page 12

Note that when browsing the locator menu, the
When browsing the transmitter menu, the
To navigate menus:
1. Press the key to enter the menu.
2. Use the or
3. Press the key to enter the option's submenu.
4. Use the or
5. Press the key to confirm a selection and return to the previous menu.
6. Press the key to return to the main operation screen.
NOTE: When you select an option and press the
automatically.
Locator menu options
• VOL: Adjust the speaker volume from 0 (mute) to 3 (loudest).
• GPS: Enable or disable the internal GPS module and enable/disable SBAS GPS
augmentation (GPS models only).
• UNITS: Select metric or imperial units.
• INFO: Run a Self-Test, display the date of the most recent service recalibration
(M CAL) or the most recent eCert calibration.
• LANG: Select menu language.
• POWER: Select local power network frequency: 50 or 60Hz.
• ANT: Enable or disable any antenna mode with the exception of Peak.
• FREQ: Enable or disable individual frequencies.
• ALERT: Enable or disable StrikeAlert™.
• BATT: Set battery type: Alkaline or NiMH. Li-Ion auto-selects when connected.
• ARROW: Select Null or proportional Guidance arrows in Peak+ mode
• COMP: Enable or disable display of the Compass feature.
Transmitter menu options
• VOL: Adjust the speaker volume from 0 (mute) to 3 (loudest).
• FREQ: Enable or disable individual frequencies.
• BOOST: Boost transmitter output for a specified period of time (in minutes).
• LANG: Select menu language.
• OPT F: Run SideStepauto
• BATT: Set battery type: ALK, NiMH or Li-Ion and enable / disable Eco mode.
• MAX P: Set the transmitter to output its maximum wattage.
keys to scroll through the menu options.
keys to scroll through the submenu options.
to auto-select a locate frequency for the connected utility.
™
and keys act as left and right arrows.
and keys act as left and right arrows.
key, the option will be enabled
12
