SPX RADIODETECTION RD7100 Guide D'utilisation page 10

Keypad actions and shortcuts
Switch the locator or transmitter on by pressing the
function as follows:
Locator keys
K EY
●
Enter the menu.
Scroll through locate frequencies
from low to high.
When using active frequencies:
Toggles Peak, Peak+, Null, and Guidance
antenna modes.
PL & PLG models in Power Mode:
Scrolls through Power Filters
discrimination of parallel or strong power
signals.
Increase and decrease gain.
RD7100 automatically sets gain to
and
mid-point when pressed.
Transmitter keys
K EY ●
Enter the menu.
Scroll through locate frequencies
from low to high.
Take voltage and impedance measurements
using the currently selected frequency.
Adjusts the output signal.
and
Tip: to scroll through frequencies from high to low, hold
(applies to both locators and transmitters).
S H O R T P R E S S
S H O R T P R E S S
key. Once powered up, the keys
● ■ ■ ■ ●
Switch power off.
–
In Peak+ antenna mode:
Switch between Guidance and Null arrows.
for improved
™
Rapidly increase and decrease gain steps
in 1dB increments.
● ■ ■ ■ ●
Switch Power off.
–
Take voltage and impedance
measurements at a standardized frequency.
Select standby
power
while pressing the
10
LON G P R E S S
LON G P R E S S
/ maximum standard
.
button
