OPERATING INSTRUCTIONS
1. Connect the charger to the battery.
2. Connect the charger to the wall socket. The power lamp will
indicate that the mains cable is connected to the wall socket.
The error lamp will indicate if the battery clamps are incor-
rectly connected. The reverse polarity protection will ensure
that the battery or charger will not be damaged.
3. Press the MODE-button to select charging program.
4. Follow the indication lamps through the charging process.
The battery is ready to start the engine when
The battery is fully charged when
5. Stop charging at any time by disconnecting the mains cable
from the wall socket.
20016605A MURS 7.0, Manual, Print file 007.indd 7
ERROR LAMP
is lit.
is lit.
MODE BUTTON
POWER LAMP
ABSORPTION, READY TO USE
ANALYSE
FLOAT, FULLY CHARGED
DESULPHATION
PULSE, MAINTENANCE CHARGING
SOFT START BULK
MODE
12V 16V
WET AGM WET AGM
12V
WET
12V 16V
BATTERY
AGM WET
PROGRAM
BATTERY BATTERY
PROGRAM PROGRAM
16V
AGM
BATTERY
PROGRAM
