2.3 Radiator installation

A – Cabin wall notch - Fig. 1
B – Radiator
C – Screen VIT-BL-L
VIT-BL-S
D – Clamping bolts
A
Fig. 4- Installation without screen
WE DO IT FIRST.
Instructions for installation and use – only for experts
stainless steel screen for IR radiator (500W/750W)
stainless steel screen for IR radiator (350W)
B
D
A B
Fig. 5 – Installation with screen
P. 7/10
C
D
