Instructions for installation and use
Parts list WELLFUN MINI
2 floor frames: 144 x 4 x 9 cm
2 floor frames: 88.5 x 4 x 9 cm – 1 x 45° diagonal
3 90° corner posts: 193 x 6 x 6 cm
2 45° corner posts: 193 x 6.4 x 6 cm
6 A/B wall elements: 193 x 44 x 4 cm (1 x with air vent)
4
A/B wall elements: 193 x 36.1 x 4 cm (1 x electrical element)
5 roof support slats: 4 x 4 cm (2 x 136 cm; 2 x 82 cm – of these, 1 x 45° diagonal;
1 x 89.7 cm – 2 x 45° diagonal)
1 roof element: 134 x 45 x 4 cm
1 roof element: 134 x 44 x 4 cm
1 roof element: 122.2 x 45 x 4 cm – 1 x 45° diagonal
2 bench support slats: 56 x 4 x 4 cm
2 bench support slats: 76 x 4 x 4 cm
2 mounting slats for bench covering: 26 x 4 x 4 cm
1 bench: 135 x 60 x 10 cm
1 bench: 135 x 31 x 10 cm
1 back rest: 135 x 27.5 x 2 cm
1 bench panel: 135 x 34 x 2 cm
1 door frame, no step: 202 x 72 x 4 cm incl. glass doors: 191.5 x 59 x 0.8 cm
1 set of door fittings
3 roof rim slats: 4 x 2 cm (2 x 90 cm – of these, 1 x 22.5°diagonal;
1 x 86.1 cm – 2 x 22.5° diagonal)
5 roof cover slats: 4 x 1.2 cm (1 x 136 cm; 1 x 132 cm; 2 x 81.4 cm – of these,
1 x 22.5° diagonal; 1 x 82.8 cm – 2 x 22.5° diagonal)
1 floor grid
1 headrest
1 ventilation shutter
1 heater safety guard: 38 x 24.5 x 7 cm 2-part, incl. mounting rail
1 third-party contact strip: 200 x 2.6 x 1.2 cm
1 silikoncabel 300 cm - 5 x.2,5 mm²
1 silikoncabel 300 cm - 3 x.1,5 mm²
1 assembly material set
1 assembly instruction manual
The parts list can also be used as a claims sheet.
p. 5/20
