Reversing The Door Swing - GE Spacemaker DSXH43 Manuel De L'utilisateur

The numbers in the illustration correspond to steps.
5 Using the blade end of a putty knife covered with
masking tape, carefully remove the hole plugs
located in the bottom of the dryer front panel.
Remove the 4 legs from the dryer base.
6
Place the dryer on top of the washer. Slide the
7
dryer back into the rear brackets (7A) then drop
the front down over the front brackets (7B).
Insert the 2 long screws provided in the kit
8
through the holes in the dryer front panel and
install into the front mounting brackets.
9 Install the hole plugs removed in step 5.
Refer to the washer and dryer installation
10
instructions for proper installation and function.
Save the top panel and brackets in the case of
11
future side-by-side use.
Reversing the Dryer Door Swing
Open the dryer door. Remove the 4 hinge hole plugs or screws
1
from the left side of door opening. Place nearby for future
installation. NOTE: You may need a plastic knife to help pull out the
plugs. Be careful not to scratch the paint.
Remove the four screws that secure the door hinges to the dryer
2
front panel. NOTE: Remove 1 screw from each of the 2 hinges first.
Hold the door firmly before removing the last 2 screws.
3 Rotate the door 180° and reinstall the door hinges to the dryer
front panel with the 4 screws.
4 Install the 4 hinge hole plugs or screws that were removed in step
1 into the open screw holes on the right side of the door opening.
Remove 4 screws—one from each hinge first
19
