Installing the dryer.
3-Wire System for Electric Dryers
1 Remove the screws securing the terminal block
access cover and the strain relief mounting
bracket located on the back of the dryer upper
corner.
Install a UL-approved strain relief into the power
2
cord entry hole of the mounting bracket. Finger-
tighten the nut only at this time.
Thread a UL-approved 30 amp power cord,
3
NEMA 10–30 Type SRDT, through the strain
relief.
Green ground screw
Green neutral
ground wire
Use copper
conductors only.
4-Wire System for Electric Dryers
1 Remove the screws securing the terminal block
access cover and the strain relief mounting
bracket located on the back of the dryer upper
corner.
2 Install a UL-approved strain relief in the entry
hole of the mounting bracket. Finger-tighten the
nut only at this time.
Remove the green neutral ground wire from the
3
green ground screw located above the terminal
block.
Typical 4
conductor
receptacle
Thread a UL-approved 30 amp power cord,
4
NEMA 14–30 type ST or SRDT, through the
strain relief.
5 Attach the green power cord ground wire to the
cabinet with the green ground screw.
Attach the white (neutral) power cord
6
conductor from the power cord and the green
ground wire from the dryer harness to the silver-
colored center terminal on the terminal block.
Tighten the screw securely.
16
Silver terminal
Nut
Tighten nut to
these threads
Strain relief
Power cord
mounting bracket
Black 240V
Typical
White neutral
4 conductor cord
Red 240V
Green ground
4 Attach the power cord neutral (center wire)
conductor to the silver-colored center terminal
on the terminal block. Tighten the screw
securely.
Attach the remaining two power cord outer
5
conductors to the outer brass-colored terminals
on the terminal block. Tighten both screws
securely.
WARNING: Do not make a sharp bend or crimp
wiring/conductor at connections.
6 Reattach the strain relief mounting bracket to
the back of the dryer with two screws. Tighten
screws securely.
Tighten the screws securing the cord restraint
7
firmly against the power cord.
Tighten the strain relief nut securely so that the
8
strain relief does not turn.
Reinstall the terminal block access cover.
9
7 Attach the red and black power cord conductors
to the outer brass-colored terminals on the
terminal block.
Green power cord ground wire
Green ground
screw
Green neutral
ground wire
Red
Strain
relief
Power cord
mounting
bracket
WARNING: Do not make a sharp bend or crimp
wiring/conductor at the connections.
8 Tighten the screws securing the cord restraint
firmly against the power cord.
Tighten the strain relief nut securely so the
9
strain relief does not turn.
Reinstall the terminal block access cover.
10
Silver terminal
Terminal block
Black
White
Nut
Tighten nut to
these threads
