Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely
hope that you are completely satisfied with the contents of your kit. However, we would ask you to check all the parts
before you start construction, as we cannot exchange components which you have already worked on. If you
find any part is not acceptable for any reason, we will readily correct or exchange it. Just send the component to our
Model Department. Please be sure to include the purchase receipt and a brief description of the fault.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit
contents in terms of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please
understand that we cannot entertain claims against us if the kit contents do not agree in every respect with the
instructions and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and operating
them safely requires a certain level of technical competence and manual skill, together with discipline and
a responsible attitude at the flying field. Errors and carelessness in building and flying the model can result
in serious personal injury and damage to property. Since we, as manufacturers, have no control over the
construction, maintenance and operation of our products, we are obliged to take this opportunity to point out
these hazards and to emphasise your personal responsibility.
Additional items required for the Mini Mag:
Adhesive and activator:
Use medium-viscosity cyano glue (not styrofoam cyano). It is important to use activator when using cyano. Epoxy
adhesives produce what initially appears to be a sound joint, but the bond is only superficial, and the hard resin breaks
away from the parts under load.
Hot-melt glues can also be used.
MULTIPLEX radio control system components for the Mini Mag:
e.g. PiCO 5/6 UNI receiver
alternatively
or Micro IPD UNI receiver
alternatively
plus optionally:
Nano S UNI or HS 55 servo (2 required)
UNI extension lead, 300 mm
if required: UNI separation filter lead, 200 mm
plus optionally:
Magicmixer #1 for three-channel RC transmitter with no mixers
UNI Y-lead for four-channel RC transmitter with sep. rudder control
Flight batteries:
e.g. MULTIPLEX Permabatt NiMH battery (AA cells),
or MULTIPLEX Permabatt NiMH battery (AA cells),
or MULTIPLEX LiBatt (LiPo) P-CS,
or MULTIPLEX LiBatt (LiPo) SX-BX,

Battery charger:

MULTIcharger LN-5014 DC (charge current 100 mA ... 5 A)
1 - 14 NiCd / NiMH cells and 1 - 5 Lithium-Polymer cells
Options:
Float set
Upgrade 1: Easy Glider power set (3 : 1 geared Permax 400)
plus 3.5 mm Ø driver
and propeller, 8 x 3.8"
Upgrade 2: "Sport" power set, BL-X 22-18
Contents: motor, propeller driver, speed controller and propeller
Tools: Scissors, balsa knife, combination pliers, slot-head and cross-point screwdrivers (servo output arms and motor
retaining screws), soldering iron if required.
Note: please remove the illustration pages from the centre of the instructions.
RR # 26 4211
35 MHz A
40 MHz
35 MHz A
40 MHz
Ailerons
Aileron servo, 2 x
Aileron servo, 2 x
7 / 1500 mAh
8 / 1500 mAh
2 / 1-2000 mAh
2 / 1-2100 mAh
GB
Order No. 5 5920
Order No. 5 5921
Order No. 5 5971
Order No. 5 5972
Order No. 6 5120
Order No. 8 5031
Order No. 8 5035
Order No. 7 3000
Order No. 8 5030
Order No. 15 6030
Order No. 15 6037
Order No. 15 7016
Order No. 15 7130
Order No. 9 2531
Order No. 73 3069
Order No. 33 2688
Order No. 33 2310
Order No. 73 3139
Order No. 33 2627
