QRP Labs QCX-mini CW Mode D'emploi page 7

Qty Value
1 39pF Label "390"
1 22pF Label "220"
1 180pF Label "181"
2 470pF Label "471"
2 1200pF Label "122"
60m(C30 is two capacitors in parallel)
Qty Value
1 39pF Label "390"
1 22pF Label "220"
1 30pF Label "300"
1 56pF Label "560"
2 680pF Label "681"
2 1200pF Label "122"
40m(no C8 capacitor)
Qty Value
1 39pF Label "390"
1 56pF Label "560"
2 270pF Label "271"
2 680pF Label "681"
30m(no C8 capacitor)
Qty Value
1 22pF Label "220"
1 30pF Label "300"
2 270pF Label "271"
2 560pF Label "561"
20m(no C5 or C8 capacitors)
Qty Value
1 30pF Label "300"
2 180pF Label "181"
2 390pF Label "391"
17m(no C5 or C8 capacitors)
Qty Value
1 30pF Label "300"
2 100pF Label "101"
Description
C5
C8
C30
C27, 28
C25, 26
Description
C5
C8
C30 (C30 is two capacitors in parallel)
C30 (C30 is two capacitors in parallel)
C27, 28
C25, 26
Description
C5
C30
C27, 28
C25, 26
Description
C5
C30
C27, 28
C25, 26
Description
C30
C27, 28
C25, 26
Description
C30
C27, 28
QCX-mini assembly Rev 1.05_Fr
Component numbers
Component numbers
Component numbers
Component numbers
Component numbers
Component numbers
7
