RESISTANCE MEASUREMENTS
1. Insert RED test lead into VΩ jack
COM jack
4
Continuity/Resistance/Capacitance/Diode-Test
NOTE: The meter defaults to Continuity testing in this mode. Press
the "SELECT" button
Resistance icon
2. Remove power from circuit.
3. Measure resistance by connecting test leads to circuit. The
meter will auto-range to display the measurement in the most
appropriate range.
Black lead
NOTE: When in a Resistance setting and the test leads are open
(not connected across a resistor), or when a failed resistor is under
test, the display will indicate O.L. This is normal.
DO NOT attempt to measure resistance on a live circuit.
OPERATING INSTRUCTIONS
, and rotate function selector switch
once to enter Resistance testing mode. The
12
will appear on the display.
Red lead
, and BLACK test lead into
5
to the
2
setting.
13
