Controls - Cafe CSB42 Manuel D'utilisation Et D'installation

Controls

Non- Dispense Models
NOTE: The refrigerator is shipped with protective film covering the temperature controls.
If this film was not removed during installation, remove it now.
The temperature controls are preset in the factory at 37°F (3°C) for the refrigerator compartment and 0°F (-18°C) for
the freezer compartment. Allow 24 hours for the temperature to stabilize to the preset recommended settings.
Changing the Temperature for Non-dispense Models
To change the temperature, press and release the
(+) or (-) pad to the desired temperature set point for
refrigerator and freezer separately. Allow 24 hours for the
refrigerator to reach the temperature you have set.
Icemaker for Non-dispense Models
To turn OFF or ON the icemaker, press and hold the
Refrigerator + and - pads at the same time and hold for
5 seconds. The temperature display will show ICE OFF
or ICE ON based on the mode and then return to normal
display after 5 seconds.
49-1000361 Rev. 2
To turn OFF cooling system, press and hold either (+)
pad until both displays show OFF.
5
