Quantum QT 600 Manual
8. Service and
maintenance
Quantum™ amps do not require service of any kind. There are
however a few basic rules that, when followed, are sure to extend
the service life of your amp considerably:
• Make sure that all peripheral devices and cables are in a state
of good repair!
• Make sure that air circulates freely around your amp's ventilation
ducts at all times.
• Absolutely avoid exposure to mechanical shocks, extreme heat,
dust and moisture.
9. Technical
specifications
9.1 Security specifications
Mains input voltage:
220 – 230V
117V
100V
Primary fuse
externally accessible
220 – 230V / T3,15A
117V / T6,3A
100V / T6,3A
Power consumption
Max. power consumption [Watt]: 950W
Inrush current
230V, 90°: A
117V, 90°: A
100V, 90°: A
Temperature indications
Surrounding temperature when in use [°C]: 0° - 70°C
Temperature during storage/transport [°C]: -20° - +85°C

9.2 Mechanical specifications

Dimensions
Absolute dimensions incl. all projecting parts WxHxD:
550mm x 195mm x 320mm
Weight
14.5kg
• Pay particular attention to the specifications of peripheral
devices. Never connect devices with high output signal levels
(e.g. amps) to your amp's input.
• Prior to plugging in your amp, always check that the AC power
source delivers the current the amp is designed to handle.
When in doubt about the local rating, ask the venue's sound
technician or a stage hand.
• Refrain from "do it yourself" repairs! Even the replacement of
internal fuses should be entrusted to an experienced technician.
• Use a soft dry cloth to clean the enclosure's outer surfaces
and metal and acrylic glass surfaces. Never use alcohol or
other solvents!
• Ensure a correct impedance matching. Never fall below an
impedance of 2.7 ohm!
9.3 Electronic/acoustic specifications
Secondary fuses
Anode voltage:
Electronics supply:
Output stage:
Inputs
Active:
Passive:
FX Return:
Footswitch connection :
Outputs
Tuner Out:
Headphone out:
FX Send:
Line Out:
DI Out:
Speaker Out:
Frequency response
Input to Line Out:
1x 50mAT
2x 630mAT
2x 8AT each IEC 5x20mm, 250V type
6.3mm mono jack
6.3mm mono jack
6.3mm mono jack
6.3mm stereo jack
6.3mm mono jack
6.3mm stereo jack
6.3mm mono jack
6.3mm mono jack
XLR male, balanced
Speakon
35Hz – 20kHz (+0/-3dB)
