9. Operator responsibility

You bought a high quality product with a long life
time. To assure the function every technical equip-
ment needs to be serviced.
Regular back washing and checks oft he filter, as
well as leak tightness checks has to be done by the
operater. According to DIN 1988-200 the filter has
to be regularly visual inspected, not later than 2
months. The filter has to be checked of leak tightness
and contamination. The filterelement has to be peri-
odically, depending on operating conditions, but at
least every 6 months changed.
Maintenance periods (change of parts):
sealing every
Manometer
Pressure reducer element (11)

10. Technical data

Protector mini HWS C/R
Nominal connection width
Flow rate**
Output pressure after pressure
reducing valve
Admission width
Nominal pressure (PN)
Operating pressure, min./max.
Water temperature, min./max.
Ambient temperature, min./max.
Connection thread A
Connection thread B
Total length C
Height D
Total length E
Height F
Art.-Nr.
EAN-Code
*810599 HWS C/R ½"
30 µm Filterelement,
without screw connection
(EAN 9022000105999)
**according to DIN EN 1567
10
3 years
every 6 years
every 6 years
Typ HWS C/R ½"
DN 15
m³/h 1,6
bar
µm
bar
bar
°C
°C
G ½"
G ¾"
mm 80
mm 170
mm 130
mm 262
810548
9022000105487 9022000105494 9022000105500 9022000105609
According to DIN EN 806-5, maintenance must be
carried out by expert technical staffs who also re-
place the parts subject to wear and tear. We recom-
mend closing a maintenance contract. This is carried
out by the installer or manufacturer.
Qualified staff: The product may only be installed,
commissioned and serviced by skilled personnel.
Only trained persons are allowed to operate and
use it.
Trained person: Has received instruction and stu-
died the information in this document concerning
the tasks entrusted to him/her, and the possible risks
in the event of inappropriate behaviour.
Skilled personnel: Based on the professional training
received, knowledge and experience, and know-
ledge of the relevant definitions, is qualified to install
the product, to commission and to service it.
HWS C/R ¾" HWS C/R 1"
20
2,8
2 – 6
100*
16
1,5 during the flushing / 16
5 / 30
5 / 40
G ¾"
G 1"
90
170
154
330
810549
HWS H/R ½"
25 15
3,7 1,6
5 / 70
G 1" G ½"
G " G ¾"
/
5
4
100 80
170 170
180 130
330 262
810550 810560
