WARRANTY
This guarantee is valid for 12 months from the date of acquisi-
tion. During this period all the material and manufacture defects
will be rectified free of charge. The following circumstances will
not be included in the guarantee:
• Absence or incorrect maintenance of the machine (view
mounting instructions and user manual)
• Inadequate use of the equipment (refer to the user manual,
safety instructions)
• Equipment repairs carried out by unauthorized personnel.
• Anomalies in the electrical supply.
• Defects caused by cables or external connections to the
equipment.
• Utilization of non-original parts.
The company refuses to accept responsibility when the damage
caused is due to incorrect use of the equipment.
In order for the guarantee to be applied it is essential to present
the purchasing invoice of the equipment along with the serial
number.
PANEL DE CONTROL
Chronometer
Main switch

SPARE PARTS LIST

14962 CARDBOARD + FILTRINE (1000 x 1015)
14963 CARDBOARD + FILTRINE (750 x 1015)
15078 FILTER G4 SUPERIOR PT REFINISH EVO (960 x 645)
15079 FILTER G4 LOWER PT REFINISH EVO (960 x 940)
11952 FILTER OF PLENUM
1853 COVS DETECTOR
4365 MASK TAPE 2.6 X 22.5

ACCESSOIRE OPTIONNEL

15989 SIDE CHIMNEY paintTROTTER Refinish Evo
16007 ROOF CHIMNEY paintTROTTER Refinish Evo
Aspiration Motor relay
Switch
Light switch Acoustic
warning
CARACTERÍSTICAS TÉCNICAS
EXTRACTED AIRFLOW:
ON-SCREEN AIR VELOCITY:
AVERAGE AIR VELOCITY ON WORK AREA:
SOUND LEVEL:
MOTOR POWER:
LIGHT POWER:
NUMER OF FILTER LAYERS:
DIMENSIONS LxHxW:
Input filter Aspiration
alarm Filter alarm
5600 - 6800 m³/h
1 m/s
0,60 - 0,70 -m/s
65 db a 1 mt.
3 Kw
0.23 kW
3 + 1
Largo 438cm
Alto 229 cm
Ancho 110 cm
