Speaker Distance - JVC EXAD KD-AVX2 Manuel D'instructions

Indications
Speaker Level*

Speaker Distance*

* 1 When activating the test tone, white noise comes out and cycles between the speakers activated on
"Speaker Size" [38] for about 2 seconds each. Press 5 / ∞ repeatedly while the test tone comes out
from the target speaker to adjust the settings (the test tone continues to come out from the target
speaker during the adjustment).
* 2 The setting is effective only when a multi-channel source is played back and Disc Surround is on, or
when Dolby PLII Movie/Music is in effect. Adjust the level on "Subwoofer" [43] for other cases.
* 3 Selectable only when DISC is the source.
* 4 Unselectable when all the speakers other than front ones are deactivated on "Speaker Size" [38].
Selectable settings, [reference page]
1 You can adjust the output level of each speaker monitoring
the test tone.
Press and hold ENT to activate (or cancel) the test tone.
• Front Lch/Center ch/Front Rch/Rear Rch/
Subwoofer*
speaker in the range of –10dB –+10dB. [Initial]; 00dB
Selects the speaker to adjust
4 You can adjust the speaker output timing separately for each
speaker according to the distance from the speakers to the
listening position.
• Front Lch/Center ch/Front Rch/Rear Rch/Rear Lch:
adjust the speaker distance in the range of 15 cm to 600 cm
in 15-cm step.
[Initial]; 120 cm (for center speaker), 150 cm (for the other
speakers)
Selects the speaker to adjust
2
/Rear Lch: adjust the output level of each
Adjusts the speaker level
Selects the speaker to adjust
Adjusts the speaker distance
Selects the speaker to adjust
39
