7 7 8
7. Discharge chute control lever
8. Drive speed control lever
9. Deflector remote control lever
10. Drive engagement
11. Steering triggers
12. Handle knob
13. Skid plate
14. Augers
15. Clean-out tool
16. Discharge chute
17. Chute deflector
18. Starter rope handle
19. Oil drain
20. Fuel switch
21. ON/OFF key
22. Primer
23. ON/OFF switch
24. Throttle control
25. Choke
26. Oil fill for all models. Dipstick (ST 3261)
27. Dipstick (ST 3268, ST 3276)
P P roduct description
The product is a wheeled snow thrower that is used to
remove snow from the ground.
Intended use
This product can be used to remove snow from fields,
roads, walkways and driveways. Do not use it on slopes
that are greater than 20°. Do not use the product in
areas where there is much debris, dirt and protruding
stones.
Symbols on the product
Note If the decals on the product are damaged, contact
the distributor to replace them.
696 - 002 - 29.06.2018
696 - 002 - 29.06.2018
Warning.
Read the operator's manual.
Engine on
Engine off.
Fast.
Slow.
Fuel.
Oil.
Ear protection recommended.
ON/OFF key. Insert to start and run.
Choke closed (start).
Primer.
Pull starter rope handle to start.
Choke open (run).
ON/OFF key. Pull out to stop.
No operation on slopes more than 10
degrees.
Do not remove shields while engine is
running.
3
