General Specifications

Vert-I-Pak
®
SERIES
DESIGN SERIES

Chassis Specifications

MODEL:
NOTES:

Electrical Data

Heater Watts 2500/2050
Voltage
Heating Current (Amps) 10.9/9.9
Minimum Circuit Ampacity
Branch Circuit Fuse (Amps )
LRA - Compressor (Amps)
Cooling Current (Amps)
Basic heater Size
Power Connection
Recommended Branch
Circuit Wire Sizes
* AWG-American Wire Gauge
Important: All 208/230v chassis must be hard wired with properly sized breaker. See nameplate for specific chassis electrical
requirements. See Figure 15, page 13 for unit wiring and wall thermostat wiring. See page 12 for wire size. Use
HACR type breakers to avoid nuisance trips. All field wiring must be done in accordance with NEC and local codes.
R=265V-1PH-60HZ
R-410A
23 1/8"
23 1/8"
32 1/4"
26" x 28 1/2" x 35"
.3" water
VEA09K
3400/2780 5000/4090
230/208
14.8/13.4 21.7/19.7
15 19.9 28.6
15 20 30
21 21 21
4.0/4.3 4.0/4.3 4.0/4.3
2.5 kW 3.4 kW 5.0 kW
HARD WIRED
14 12 10
25 = 2.5 KW
34 = 3.4 KW
; 265
R-410A
23 1/8"
23 1/8"
32 1/4"
26" x 28 1/2" x 35"
See Charts A & B (page 11)
.3" water
VEA12K
2500/2050 3400/2780
230/208
10.9/9.9 14.8/13.4
15 19.9
15 20
29.5 29.5
5.0/5.4 5.0/5.4
2.5 kW 3.4 kW
HARD WIRED
14 12
ENGINEERING CODE
OPTIONS
; 265
23 1/8"
23 1/8"
32 1/4"
26" x 28 1/2" x 35"
.3" water
VEA18K
5000/4090 2500/2050 3400/2780
230/208
21.7/19.7 10.9/9.9 14.8/13.4
28.6 15
30 15
29.5 42
5.0/5.4 8.1/8.6
5.0 kw 2.5 kW
HARD WIRED
10 14
; 265
R-410A
5000/4090
21.7/19.7
19.9 28.6
20 30
42 42
8.1/8.6 8.1/8.6
3.4 kw 5.0 kW
12 10
2
