Operating Instruction

1. Machine overview

18
17
16
15
14
13
1 Compressor pump
2 Air intake filter housing
3 On/Off switch
4 Safety valve
5 Motor protection
6 Transport handle
7 Outlet for unregulated com-
pressed air
8 Swivel plate casters, lockable
9 Motor
ENGLISH
1 2
12
11
10
9
10 Pressure vessel
11 Condensate drain cock of pres-
sure vessel
12 Tank pressure gauge
13 Outlet for regulated com-
pressed air
14 Oil drain plug
15 Oil sight glass
16 Pressure regulator
17 Outlet pressure gauge
18 Oil filler plug
3
4
5
ENGLISH
6
7
8
9
