Approvals
Hella marine 3NM NaviLED PRO masthead lamps are type approved according to the
®
European norm EN 14744, 2005 and EN 60945, 2002 and they are certified by the German
Federal Maritime and Hydrographic Agency (BSH) for German inland waterways and the open
sea for powerboats and sailing boats under motor less than 20m in length. They carry the
following approval numbers: D.06.419 and
EC Type examination (Module B) Certificate: BSH/4612/6010947/08
0735/yy: EC Quality System (Module D) Certificate: BSH/4613/072/0670/08
for the "Wheelmark" approval according to the Marine Equipment Directive 96/98/EC (MED).
The relevant declaration of conformity is available for download on www.hellamarine.com .
NaviLED PRO Self Diagnostic Control
®
To ensure long term safety at sea, each BSH certified NaviLED
equipped with a self diagnostic control.
A photometrical self-test is carried out by the lamp in periodic intervals. If the light output, and
consequently the visibility, reaches a pre-determined value, the lamp activates 'Service Mode'.
Service Mode is indicated by the lamp flashing at a rate of 60 flashes per minute for 15 sec-
onds as soon as the lamp is switched on. This will occur for 15 seconds every time the lamp is
switched on until the unit has operated for 2000 hours.
After 2000 hours the Service Mode flash rate doubles to 120 flashes per minute for 15 seconds
as soon as the lamp is switched on.
To ensure the lamp meets the light output criteria of its certification, Hella marine recommends
the light module be replaced as soon as it enters this 2000 hour Service Mode stage.
The 2000 Service Mode flash rate should not occur earlier than tens of thousands of hours. By
regular recreational boating standards, even with regular night sailing, this stage will hardly ever
be reached.
Warranty Statement
Congratulations! The product you have selected comes from Hella marine - one of the
world's leading manufacturers of marine lighting products.
Hella marine branded products are covered by a warranty against manufacturing or
material defects. (For further details please check the terms of trade with your Hella marine
agent).
The lamp module is sealed and does not have any serviceable parts inside; opening the
module will invalidate warranty.
In the unlikely event that you should experience a problem with your purchase,
please contact your Hella marine agent where you purchased the product.
For general comments about Hella's products please contact us on E-mail
at techfeedback@hellamarine.com
PRO navigation lamp is
®
PR O
BSH certified NaviLED
225° Masthead Navigation Lamp
Introduction
Hella marine LED Navigation Lamps offer many advantages over conventional bulb lamps.
Significantly reduced power consumption, ultra long life and high tolerance to shock and vibration
make the LED lamps the ideal choice for the harsh marine environment.
Hella marine NaviLED PRO Navigation Lamps are 'Precision Optical Instruments', tested and
®
type approved to comply with international maritime regulations.
Positioning of the lamp:
The masthead lamp must be positioned at
right angles to the vessel's centre line with the
signal direction arrow pointing straight ahead.
(see Fig. 1)
Prevent obstruction to the light output
When the lamp is operating, the light should
not be obstructed or concealed by superstruc-
tures or other objects.
Vertical Positioning
On a powerboat between 12 and 20 metres in
length the Masthead lamp must be placed at
a height above the gunwale of not less than
2.5 metres.
On a powerboat less than 12 metres in length
the Masthead lamp must be placed at least 1
metre higher than the sidelights.
Horizontal Positioning
On a powerboat less than less than 20 metres
in length the Masthead lamp need not be
placed forward of amidships, but must be
placed as far forward as practicable taking
into account the vertical positioning require-
ments above the gunwale or sidelights as
described above.
(see Fig. 2)
N.b. The relevant country specific rules have
to be taken into consideration.
PRO 3 Nautical Mile
®
Fig. 1 Right angles to the vessel's centre line
Top view
TOP
Made in New Zealand
2LT 959 940
225 Degrees
Fig. 2 Horizontal Positioning
Amidships
