Residual Risks; Know Your Product - Ryobi RBDS4601G Traduction Des Instructions Originales

BELT / DISC SANDER SAFETY WARNINGS
Do not operate the tool until it is completely assembled
and installed according to the instructions.
Before work, check that the machine is placed on an
even surface with sufficient stability. For your own
safety, always mount the machine to a work bench
using bolts.
Keep the surrounding area of the machine well
maintained and free of loose materials, such as chips
and cut-offs.
Make sure the sanding belt is installed in the correct
direction. See directional arrow on back of belt.
Always have the tracking adjusted properly so the belt
does not run off the pulleys.
Do not use sanding belts or pads that are damaged,
pad.
Always sand on the downward side of the sanding disc
when using the disc sander. Sanding on the upward
side of the disc can cause the workpiece to fly out of
position, resulting in injury.
Never perform layout, assembly or set-up work on the
table while the sander is operating.
Always hold the workpiece firmly when sanding.
Use clamps or a vise to hold work when practical.
long workpieces.
Never sand more than one workpiece at a time. Do not
stack more than one workpiece on the machine base
at a time.
Do not sand with the workpiece unsupported. Do not
sand pieces of material that are too small to be safely
supported.
Avoid awkward operations and hand positions where
a sudden slip could cause your hand to move into the
sanding belt or disc.
Avoid kickback by sanding in accordance with
directional arrows.
Always maintain a clearance of 1.6 mm between the
work table and the machine.
Never stand or have any part of your body in line with
the path of the workpiece.
Machine should never be connected to power supply
when you are assembling parts, making adjustments,
or when not in use.
Never leave tool running unattended. Do not leave tool
until it comes to a complete stop.
If the power supply cord is damaged or otherwise
defective, it must only be replaced by the manufacturer
We recommend the use of a residual current device
with a residual current rating of 30mA or less.
2

RESIDUAL RISKS

Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
should pay special attention to avoid the following:
Risk of contact with sanding belt or disc.
piece.
Damage to respiratory system if effective dust mask is
not worn.
Damage to hearing if effective hearing protection is not
worn.

KNOW YOUR PRODUCT

See page 85.
1. Sanding stopper
2. Sanding belt
3. Tracking control knob
4. Belt tension lever
5. Sanding pad
6. On/off switch
7. Bevel scale
8. Dust port
9. Table bevel angle adjustment knob
10. Mitre angle adjustment knob
11. Mitre scale
12. Mitre guide
13. Work table
MAINTENANCE
Do not modify the product in any way or use accessories
not approved by the manufacturer. Your safety and that
of others may be compromised.
Do not use the product if any switches, guards or
other functions does not work as intended. Return to
an authorised service centre for professional repair or
adjustment.
Do not make any adjustments whilst the product is
running.
Always make sure the power plug has been
removed from the mains power source before
making adjustments, lubricating or when doing any
maintenance on the product.
Before and after each use, check the product for
damage or broken parts. Keep the product in top
working condition by immediately replacing parts with
spares approved by the manufacturer.
Clean out accumulated dust using a brush or vacuum
cleaner. Do not use compressed air.
To assure safety and reliability, all repairs, including
changing brushes, should be performed by an
authorised service centre.
