RATCHET WRENCH
Izjave
IZJAVA EU O SKLADNOSTI
V družbi Desoutter GmbH, Edmund-Seng-Str. 3-5, 63477
Maintal, Germany, na izključno lastno odgovornost izjavl-
jamo, da je izdelek (z imenom, tipom in serijsko številko z
naslovnice) skladen z naslednjimi direktivami:
2006/42/EC (17/05/2006)
Uporabljeni usklajeni standardi:
EN ISO 11148-6:2012
Pristojni organ lahko zaprosi za pridobitev potrebnih
tehničnih podatkov pri:
Pascal Roussy, R&D Manager, Ets Georges Renault, 38 rue
Bobby Sands, BP10273 44818 Saint Herblain, France
Saint-Herblain,
Pascal ROUSSY
Podpis izdajatelja
Additional Vibration Information
This tool may cause hand-arm vibration syndrome if its
use is not adequately managed.
This additional vibration information may be of assistance to
employers in meeting their obligations (for example under
EU Directive 2002/44/EC) to assess the risks to their workers
arising from hand arm vibration associated with the use of
this tool.
Ratchet wrenches are suitable for assembly and disassembly
operations in confined spaces.
• The declared vibration value can be used to estimate vi-
bration during rundown. Continuous ratcheting against a
run-down bolt may produce a vibration emission in the
2
2
range m/s
to m/s
(vibration total values).
• Only use this tool for work which other types of
wrenches, which present lower vibration risks, are un-
able to perform satisfactorily.
• The vibration emission varies greatly with task and oper-
ator technique. Emissions outside the quoted range may
occur for some applications.
• Operators should optimize their technique and select a
suitable wrench in order to minimize the ratcheting time
at the end of each run-down or when backing-off assem-
bled fasteners.
• For the intended application of this tool, we estimate that
normal operation should involve a ratcheting time
against a run-down fastener of less than 0,5s per fastener
on a hard joint and up to 3s on a soft joint.
Koristne informacije
Avtorske pravice
© Avtorske pravice 2019, Desoutter GmbH, Edmund-Seng-
Str. 3-5, 63477 Maintal, Germany
Vse pravice pridržane. Vsaka nepooblaščena uporaba ali
razmnoževanje vsebine ali delov vsebine je prepovedano. To
še posebej velja za blagovne znamke, označbe modelov,
številke delov in slike. Uporabite samo pooblaščene dele.
Garancija ali jamstvo za izdelek ne krije nobenih poškodb ali
nepravilnega delovanja, ki ga povzroči uporaba
nepooblaščenih delov.
Država izvora
China
Date tehnice
dimensiune filet ad-
misie aer (")
Turaţie la gol (rpm)
Cuplu max. (Nm)
Cuplu util max. (Nm) 30
Antrenor pătrat (")
Greutate (kg)
Nivel presiune sunet
(dB(A))
Vibraţie (m/s²)
Declaraţii
DECLARAŢIE DE CONFORMITATE UE
Noi, Desoutter GmbH, Edmund-Seng-Str. 3-5, 63477 Main-
tal, Germany, declarăm pe propria răspundere că produsul
(cu denumirea, tipul şi numărul de serie - vezi prima pagină)
este conform cu următoarea Directivă / următoarele Direc-
tive:
2006/42/EC (17/05/2006)
Standarde armonizate aplicate:
EN ISO 11148-6:2012
Autoritățile pot solicita informații tehnice corespunzătoare de
la:
Pascal Roussy, R&D Manager, Ets Georges Renault, 38 rue
Bobby Sands, BP10273 44818 Saint Herblain, France
Saint-Herblain,
Pascal ROUSSY
Semnătura emitentului
© Rodcraft - 8956001776
RC3068 RC3268 RC3278 RC3678
1/4
1/4
1/4
BSPP
BSPP
BSPP
280
280
190
45
50
100
25
60
1/4
3/8
3/8
0.67
0.68
1.22
RC3068 RC3268 RC3278 RC3678
92.9
92.9
89.2
8.5
8.5
9.2
1/4
BSPP
190
100
60
1/2
1.23
89.2
9.2
21
