Stop the product
ASSEMBLY
UNPACKING
The product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
■ Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the tool.
PACKING LIST
■ Grass trimmer/Brushcutter x 1
■ ReelEasy™ grass trimmer head x 1
■ Cutting attachment guard x 1
■ Tri-Arc™ blade x 1
■ Harness x 1
■ Operator's manual x 1
■ Engine oil x 1
■ Combination wrench x 1
■ Wrench x 1
■ Allen wrench (5 mm) x 1
■ Allen wrench (4 mm) x 1
■ Blade nut x 2
WARNING
If any parts are damaged or missing, do not operate the
product until the parts are replaced. Failure to heed this
warning could result in serious personal injury.
WARNING
Do not attempt to modify the product or create
accessories not recommended for use with the product.
Any alteration or modifi cation is misuse and could result
in a hazardous condition leading to possible serious
personal injury.
WARNING
Never attach or adjust any attachment while power
head is running. Failure to stop the engine may cause
serious personal injury.
English (Original instructions) English (Original Instruction)
Make sure all knobs and fasteners are fully tightened
before operating the product; check it periodically for
tightness during use to avoid serious injury.
SETTING UP THE FRONT HANDLE
See fi gure 2.
1. Remove the four bolts from the front handle.
2. Position the front handle onto the shaft.
3. Position the bracket barrier underneath the front
ATTACHING THE HARNESS
See fi gure 3.
1. Connect the latch on the harness to the strap hanger.
2. Adjust the strap hanger to a comfortable and balanced
FITTING THE CUTTING ATTACHMENT GUARD
See fi gure 4.
1. Attach the cutting attachment guard to the mounting
2. Tighten the screws.
When using the ReelEasy™ grass trimmer head, the
grass defl ector must be attached to the blade guard.
See fi gure 21. When using the Tri-Arc™ blade, the
grass defl ector must be removed from the blade guard.
See fi gure 20.
INSTALLING THE REELEASY™ GRASS TRIMMER
HEAD
See fi gure 5.
1. Stop the engine.
2. Place the Allen wrench through the hole in the upper
3. Remove the blade nut, blade washer, and cupped
18
WARNING
NOTE: The lever protruding from the front handle
should point to the left side of the trimmer.
handle and secure it in place by screwing the bolts
through the base of the front handle into to the bracket.
position where the blade or cutter attachment will
suspend between 100 mm and 300 mm above the
ground surface.
NOTE: Always use the harness with the product.
NOTE: To quickly release the product from the
harness, sharply pull the quick-release tab.
bracket and align the screw holes on the cutting
attachment guard to the screws on the mounting
bracket.
WARNING
fl ange washer and the hole in the gear head. Turn the
blade nut clockwise to remove.
