INSTALLING RECEIVER
1) Remove the electronic card from the plastic box.
2) Fix the plastic box with the cable input downwards near the gate
control unit, at high level from the ground (Fig. 4).
3) Reinsert the electronic card into the plastic box.
4) Connect the receiver's COSTA 1 ("EDGE1") output to the gate
control unit's safety input.
5) Use the jumper (7 in Fig. 5) to select the COSTA 1 ("EDGE1")
output that is most suited to the control unit safety input, i.e.
N.C. type or 8.2 kOhm.
6) Connect the power supply to the corresponding receiver
terminals (5 in Fig. 5) after selecting the correct voltage by
means of the jumper (8 in Fig. 5).
PROGRAMMING
1) Press the Pr1 memorisation button on the receiver (3 in Fig. 5).
The LED alongside begins to flash.
2) Within a few seconds press button Pt1 on the transmitter (1 in
Fig. 2) and hold down until the LED alongside begins to flash.
If the operation is successful, the buzzer on the receiver emits a
sound.
