N
GND
L
BK
BK
LED
WH
BK
LED
WH
RD
OUTPUT: 700mA
(2-15VDC)
LED
DRIVER
INPUT: 120VAC
12
WIRING DIAGRAM
BR
BU
YL
WH
RD
BK
BK
BU
1
2
RD
+
BK
-
YL
BU
BR (LINE)
BU (NEUTRAL)
YL (LAMP)
WH (SPEED 1)
RD (SPEED 2)
BK (SPEED 3)
7
9
3
4
5
6
8
M
SE134B
MECHANICAL PUSH BUTTONS
WITH BACKLIGHT
PUSH BUTTON
SWITCH OPERATION
FUNCTION
POSITION
OFF
NO CONNECTION
LAMPS
BROWN / YELLOW (1-3)
LOW SPEED
BROWN / WHITE (1-4)
MED SPEED
BROWN / RED (1-5)
HIGH SPEED
BROWN - BLACK (1-6)
MOTOR SPECIFICATIONS
POWER SUPPLY
120 VAC
FREQUENCY
60 Hz
POWER ABSORTION
240 W
MOTOR RESISTANCE ( )
BLUE / BLACK
28.8
BLUE / GREY
30.3
BLUE / RED
37.7
BLUE / WHITE
45.1
