17 programs available list for parameter 1:
Code
Description
01
Output voltage
02
Output frequency
03
Voltage range for bypass
04
Frequency range for bypass
05
ECO mode enable/disable
06
Voltage range for ECO mode
07
ECO mode frequency range setting
08
Bypass mode setting
09
Battery backup time setting
10
Programmable output setting
Shutdown point for programmable
11
output
12
Reserved /Neutral Loss**
13
Battery voltage adjustment
14
Charger voltage adjustment
15
Inverter voltage adjustment
16
Output voltage calibration
17
Phase auto adapt enable/disable***
*Y means that this program can be set in this mode.
**It is only available to operate when a loss of neutral line is detected. Otherwise, it will display "
menu.
***This function can get UPS input phase sequence more flexible. If it is enabled, UPS can adapt several kinds of phase
order even it works like single phase UPS. If it is disabled, UPS only can work under standard input phase sequence between
L1/L2/L3. More details about LCD setting, please refer to program 17 below.
Note: All parameter settings will be saved only when UPS shuts down normally with internal or external battery
connection. (Normal UPS shutdown means turning off input breaker in bypass/no output mode).
01: Output voltage
Interface
02: Output frequency
Interface
60 Hz, CVCF mode
INFOSEC UPS SYSTEM – 4 rue de la Rigotière – 44700 Orvault – France – www.infosec-ups.com
63
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 04 14 AA 59 203 37
Bypass /
No Output mode
Y*
Y
Y
Y
Y
Y
Y
Y
Y
These functions are not supported by the Rack model.
Y
Y
Y
Setting
Parameter 3: Output voltage
You may choose the following output voltage in parameter 3:
208: Presents output voltage is 208Vac
220: Presents output voltage is 220Vac
230: Presents output voltage is 230Vac
240: Presents output voltage is 240Vac
Setting
Parameter 2: Output Frequency
Setting the output frequency. You may choose following three
options in parameter 2:
50.0Hz: The output frequency is setting for 50.0Hz.
60.0Hz: The output frequency is setting for 60.0Hz.
ATO: If selected, output frequency will be decided according to
AC
ECO
CVCF
Battery
mode
mode
mode
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Battery
mode
Test
Y
Y
Y
Y
Y
Y
Y
Y
" in program setting
