Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The fol-
lowing hazards may arise in connection with
the equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is applied.
Warning!
This equipment generates an electromag-
netic fi eld during operation. Under certain
circumstances this fi eld may actively or pas-
sively impede medical implants. To reduce
the risk of serious or fatal injuries, we recom-
mend persons with medical implants to con-
sult their doctor and the manufacturer of the
medical implant prior to using the equipment.
5. Before starting the equipment
The lawn mower is delivered partly assembled.
The push bar and the grass basket must be as-
sembled before using the lawn mower. Follow the
instructions step by step and refer to the pictures
when assembling.
Important! Required assembly parts (screws,
cable guides, etc.) or functional parts (e.g. plugs,
wrenches, etc.) can be found in the molded parts
of the packaging or on the equipment.
There are three contacts on the right-hand teeth
of the handlebar adjustment facility (Fig. 3), as
well as on the right-hand push bar. The contacts
are for connecting the electrical connections of
the motor and switching bar.
Fitting the push bar
Use the quick-tightening screws (Fig. 2/Item 16)
to fasten the push bar (Fig. 4/Item 13) to the teeth
of the handlebar adjustment facility. If necessary,
turn the quick-tightening screw back suffi ciently
on the thread so that the quick-release lever (Fig.
4/Item 16a) can then still be fl ipped down towards
the back.
You can adjust the angle of the long handle as a
whole by fl ipping up the two quick-release levers
(Fig. 5/Item 16a), with three settings available
for the angle (Fig. 5). Only these three positions
are available. As you do this, make sure that both
sides are set to the same position. To secure the
Anl_Rasarro_SPK9.indb 24 Anl_Rasarro_SPK9.indb 24
GB
push bar again, fl ip the two quick-release levers
back into the closed position.
Flipping up the two tube locks (Fig. 6/Item 4) will
enable you to adjust the length of the upper push
bar (Fig. 6/Item 1). As you do this, make sure that
both sides are set to the same position. To secure
the upper push bar again, fl ip the two tube locks
back into the closed position.
Fitting the catch basket
Slot the two bottom parts of the housing Item
10a and Item 10b together (Fig. 7/8). Then fi t the
top part of the housing (Fig. 9/Item 11) to the two
halves which have already been fi tted together.
Finally, press the carry-handle (Fig. 10/Item 14)
onto the top part of the housing of the catch bas-
ket. During assembly, make sure that there is an
audible click when you fi t the individual parts of
the housing together. Before you fi t the catch bas-
ket you must ensure that the motor is switched off
and the blade is not rotating. Lift the ejector fl ap
(Fig. 11/Item 7) with one hand. Using the other
hand, grab onto the basket by the handle and
hang it in from the top.
Filling level indicator of the grass collector
The grass collector is equipped with a fi lling level
indicator (Fig. 12/Item 12). which is opened by the
airfl ow that the lawn mower generates during ope-
ration. If the fl ap closes during mowing, the grass
collecting device is full and must be emptied. To
ensure the proper functioning of the fi lling level
indicator, the holes under the fl ap must always be
kept clean and passable.
Using the mulching adapter (Fig. 13)
In mulching mode the cuttings are shredded in
the enclosed mower housing and then spread
back onto the lawn. It is not necessary to gather
and dispose of the grass.
Important! Mulching is only possible if the lawn
is relatively short. Mow the lawn regularly in order
to obtain a thin layer of mulch.
Warning!
Insert the mulching adapter only when the mo-
tor is switched off and the safety plug has been
pulled out.
To use the mulching function, disconnect the
catch bag, slide the mulching adapter (Fig. 13/
Item 15) through the ejector opening and close
the ejector fl ap again.
