Pressalit R4750 Notice De Montage page 21

R4750 - R4751
340 200
200 260
(13³⁄8) (7⁷⁄8) (7⁷⁄8) (10²⁄8)
Ø32 (1 ⁄ )
340
153
200
(13³⁄8)
(7⁷⁄8) (6)
Ø32 (1 ⁄ )
340 153 200
(13³⁄8) (6) (7⁷⁄8)
Ø32 (1 ⁄ )
