TABLE OF CONTENTS
Product Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Instructions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
READ AND FOLLOW SAFTY INSTRUCTIONS
This is the safety alert symbol. When
you see this symbol on your filter or in
this manual, look for one of the follo-
wing signal words and be alert to the
potential for personal injury.
warns about hazards that will
cause death, serious personal
injury, or major property damage if ig-
nored.
warns about hazards that can
cause death, serious personal injury,
or major property damage if ignored.
warns about hazards that will
or can cause minor personal
injury or property damage if ignored.
NOTICE:
indicates special instructions not rela-
ted to hazards. Carefully read and fol-
low all safety instructions in this ma-
nual and on equipment. Keep safety
labels in good condition; replace if
missing or damaged.
Incorrectly installed or tested
equipment may fail, causing
severe injury or property damage.
Read and follow instructions in pres-
sure owner's manual when installing
and operating equipment. Have a -
trained pool professional perform all
pressure tests.
1. Do not connect system to a high
pressure or city water system.
2. Use equipment only in a pool or spa
installation.
3. Trapped air in system can cause ex-
plosion. BE SURE all air is out of sys-
tem before operating or testing equip-
ment.
Specifications
Installation
Module Cleaning Procedure
System Inspection/Winterizing
12
Troubleshooting Guide
13
Repair Parts List
14
Before pressure testing, make the fol-
lowing safety checks:
Check all clamps, bolts, lids, and
system accessories before testing.
Release all air in system before
testing.
Tighten Sta-Rite trap lids to 30 ft.
lbs. (4.1 -kg-cm) torque for testing.
Water pressure for test must be
less than 3,5 bar.
Water Temperature for test must
be less than 40°C.
Limit test to 24 hours. After test, vi-
sually check system to be sure it is
ready for operation. Remove trap lid-
and retighten hand tight only.
NOTICE:
These parameters apply to Sta-Rite
equipment only. For non-Sta-Rite
equipment, consult equipment manu-
facturer.
- PLM 100/150/175/200 -
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
W A R N I N G
Can cause tank explosion.
Do not connect filter to compres-
sed air under any circumstan-
ces.
13
Page
16
17
19
20
21
22
