– Local operating restrictions – for example, in hospitals, aircraft,
petrol stations or in the vicinity of people with pacemakers – may apply.
Electronic devices can potentially cause hazards or interference or
be subject to hazards or interference.
– The measuring accuracy may be affected when working close to high
voltages or high electromagnetic alternating fields.
Safety instructions
Dealing with RF radiation
– The measuring device is equipped with a wireless interface.
– The measuring device complies with electromagnetic compatibility
and wireless radiation regulations and limits in accordance with
the RED 2014/53/EU.
– Umarex GmbH & Co. KG hereby declares that the DistanceMaster
Compact Pro radio equipment complies with the essential
requirements and other provisions of the European Radio
Equipment Directive 2014/53/EU (RED). The EU Declaration
of Conformity can be found in its entirety at the following address:
http://laserliner.com/info?an=ACH
Inserting batteries
Open the battery compartment and insert batteries according
to the symbols. Be sure to pay attention to polarity.
a
b
l
4.658m
k
11.237m
j
52.342m
DistanceMaster Compact Pro
(see Fig. A)
c
d
e
f
30.0°
g
h
i
DISPLAY:
a Display length / area / volume /
Angle function 1 + 2 + 3
b Bluetooth
function
®*
c Malfunction / service required
d Memory
e Bluetooth
function activated
®*
f Battery symbol
g Measured value, angle function
h Intermediate values /
min/max values
i Measurement values /
Measurement results
Unit m / ft / inch / _' _"
j min/max continuous
measurement
k Measurement point (reference)
rear / front
l The bar diagram shows how well
suited the reflection surface is for
measurement. This is particularly
useful for measuring over long
distances, dark surfaces or bright
ambient light.
13
EN
