Features
Front Panel
1. Power Switch: Use this switch to power RM6 on or off.
2. Power Light: This light illuminates when RM6 is powered on.
3. Mic In Level: Turn these knobs to set the input level of the corresponding mic/line inputs.
4. Signal (Sig) Lights: Indicates that the channel's incoming audio signal is within an optimal
range.
5. EQ: Turn these knobs to increase ("boost") or reduce ("cut") the amount of bass frequencies
(Low), mid-range frequencies (Mid), and treble frequencies (High) of the main mix.
6. Master Level: Turn this knob to adjust the level of the Line Outs, Mono Out, and Rec Out.
7. Level Meters: These lights indicate the audio level of the Line Outs. The Clip light can
light up occasionally, but if it happens too often, reduce the volume of the mix and/or
individual channels.
3
4
5
7
2
6
1
3
