GB
b Attaching the trimmings collector (Fig. 5a-5d)
For horizontal trimming it is recommended that
you attach the trimmings collector. This enables
the trimmings to be removed more easily,
keeping the surface of the hedge tidier in the
process.Place the trimmings collector on the
cutter rail (Fig. 5c). Then slide the trimmings
collector towards the tip of the cutter as far as
the stop and tighten the fastening screws (16)
(Fig. 5d). The trimmings collector can be fitted
either on the left-hand or the right-hand side.
7. Using for the first time and operation
The hedge trimmer comes with a two-hand safety
switch. It only works if the switch on the guide handle
(Fig. 6a / Item A) is pressed with one hand and either
the switch on top of the handle (Fig. 6a / Item B) or
the switch below the handle (Fig. 6a / Item C) is
pressed with the other hand.
Releasing any of the switches will bring the hedge
trimmer to a stop.
In so doing, please check the running of the
blades.
b Please check that the blades function correctly.
The blades cut on both sides and run in opposite
directions to each other, for guaranteed high
cutting performance and quiet operation.
b Fasten the extension cable to the cable holder
before starting to use the machine (see Fig. 6b).
b For use in the open air you must only use
extension cables certified for the purpose.
Tips on use
b The hedge trimmer can be used not only for
trimming hedges but for trimming shrubs and
bushes as well.
b For optimum trimming performance, guide the
blade teeth at an angle of approx. 15° to the
hedge (see Fig. 7).
b Since the blades cut on both sides and run in
opposite directions to each other, you can trim in
both directions (see Fig. 8).
b To achieve a hedge with a uniform height it is
recommended that you stretch a piece of string
along the edge of the hedge for guidance. Then
simply cut away all twigs projecting above the
line (see Fig. 9).
b The sides of the hedge should be trimmed with
arc-type movements from below upwards (see
Fig. 10).
12
07.03.2012 7:47 Uhr Seite 12
8. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
9. Cleaning, maintenance and
ordering of spare parts
Always pull out the mains power plug before starting
any cleaning work.
9.1 Cleaning
b Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
b We recommend that you clean the device
immediately each time you have finished using it.
b Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts
of the equipment. Ensure that no water can seep
into the device.
9.2 Maintenance
b Um stets beste Leistungen zu erhalten, sollten
die Messer regelmäßig gereinigt und geschmiert
werden. Entfernen Sie die Ablagerungen mit
einer Bürste und tragen Sie einen leichten Ölfilm
auf (siehe Bild 11).
b There are no parts inside the equipment which
require additional maintenance.
b Zur Aufbewahrung kann die Heckenschere mit
passender Schraube und Dübel an der Wand
befestigt werden (siehe Bild 12).
9.3 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
