MAIN UNIT
1. Turntable platter
2. Turntable Shaft
3. 45 RPM Adaptor
4. Tone arm lift
5. Tone arm
6. Head phone jack
7. Speed control selection
8. Power indicator
9. Auto stop on/off switch
10. Power/Volume control knob
11. 3.5mm line in jack
12. Stylus (needle) Cartridge
13. Built-in speak
14. Handle
15. Lock
16. RCA line-out L/R
17. DC in power jack
POWER SUPPLY
AN AC DC Adaptor with the output 5V DC 1A (included)is required for operating the main unit .To
connect the AC-DC Adaptor to the unit and 230V~60Hz AC outlet:
Firmly and securely insert the DC plug of the adaptor to the DC IN JACK on the back of the unit.
Plug the adaptor s AC plug into a power outlet rated at 230V AC~60Hz.
Rotate the POWER/VOLUME ON/OF SWITCH clockwise to turn on the system. The power indicator
Will light on.
PARTS / BUTTONS

GETTING STARTED

GB-2
