6 COMMISSIONING AND OPERATION
6.1
AIRQURE P1-N
The unit runs at the set continuous running speed (low). The maximum speed can be activated by means a remote dedicated
switch (wiring diagram Fig. 5.i).
The speeds can be set during the commissioning according to the ventilation rate needed, by means of the trimmer V1 and V2
(Fig.6.a).
Factory setting (default):
V1 (min speed) 104m
/h (29l/s).
3
V2 (max speed) 216m
/h (60l/s).
3
6.2
AIRQURE P1-H
6.2.1 Setting of the continuous running (low) speed
To set the continuous running (low) speed use the dip switches 1-2-3.
DIP1
0
0
0
0
1
1
1
1
6.2.2 Setting of the maximum speed
To set the maximum speed use the dip switch 4.
DIP4
0
1
18
Fig. 6.a
Trimmer position
m
3
A (min)
61
B
76
C
104
D
144
E
180
F
198
G (max)
216
DIP2
DIP3
m
0
0
104
0
1
61
1
0
76
1
1
90
0
0
119
0
1
133
1
0
148
1
1
162
Maximum speed
m
/h
l/s
3
216
60 (default)
180
50
/h
l/s
W
17
3,7
21
4,3
29
7,5
40
12,0
50
17,3
55
21,0
60
24,2
Low speed
/h
l/s
3
29 (default)
17
21
25
33
37
41
45
TRIMMER
D
C
E
B
F
A (min)
G (max)
DIP SWITCHES
1
0
1
2 3
4
DIP SWITCHES
1
0
1
2 3
4
