1. PRODUCT DESCRIPTION
1
2
240VAC
3
24VDC
24VDC
4
Optie
Code: 8600.060101
1. Configuration code (DPC.XXXXXX)
2. Ccontroller
3. Power supply 240 VAC (IN) / 24 VDC (OUT)
4. Option: Mains voltage 24VDC
5. Control panel
28
5
JAGA N.V. | DBH SET - TPT | MANUEL | 2021.03.25 | V.03
9
6. Room temperature sensor (Tk)
7. Water temperature sensor (Tw)
8. Activator unit
9. Connection cable thermo-electrical motor
10. Cover plate
6
7
8
10
