Environmental conditions
During operation:
– Ambient temperature -40 to +80 °C
– Pressure 700 to 1300 hPa
in potentially explosive atmospheres:
800 to 1100 hPa
– Humidity 5 to 95 % rel. humidity,
non-condensing
During storage: -40 to +80 °C, 700 to 1300 hPa,
5 to 95 % rel. hum., non-condensing
Approvals ATEX 2014/34/EU
Type RCU 0010
Dräger Safety, D-23560 Lübeck, Germany
–40 °C ≤ Ta ≤ +65 °C / 80 °C
TPS 18 ATEX 53474 026X
NON-INTRINSICALLY SAFE CIRCUITS
INTERNALLY IP30 PROTECTED
Year of construction via serial number
The Dräger RAB 7000 (RCU 0010) is
tested using measurement technology
(EN 60079-29-1) to assess its suitability
for use with the PIR 7000.
1) Configuration of serial numbers: The third letter of the serial number represents the year
of manufacture: M = 2019, N = 2020, P = 2021, R = 2022, S = 2023, T = 2024, U = 2025,
W = 2026, X = 2027, Y = 2028, Z = 2029 etc. (letters G, I, O, Q are omitted)
Example: Serial number ARMB-0001: The third letter is M, i.e. the device was
manufactured in 2019.
40
II 2G Ex db eb IIC T6 / T4 Gb
II 2D Ex tb IIIC T80 °C / T130 °C Db
IP6x

Drilling template

 See page 230.

Order list

Name and description
Remote access box
Dräger RAB 7000 (RCU 0010)
Big housing,
incl. cable gland and blind plug
Accessories
Special tool
To open the spring terminals,
made of plastic
Spare parts
Converter module
1)
Order number
68 12 830
83 18 376
68 12 831
