EQUALIZER LOW CH 1
14
Equalizer bass band for channel 1 (CH 1). When turned to the left, levels are lowered, when turned to the right, they are raised. In the centre position
(resting point), the equalizer is inactive.
LEVEL DFX CH 1
15
Controller for adding the signal from channel 1 (Effects Send) to the internal digital effects device (effect volume channel 1). The effect presets are
selected with the help of the rotary encoder DFX PRESETS Nº 31.
16 LED CH 2
When a signal is present at the input of channel 2 (CH 2), the LED indicator lights up green; if the LED is red, the channel is operating in the clipping
range. To avoid distortion, reduce the volume level of the volume controller (17) of channel 2.
17 LEVEL CH 2
Volume controller for channel 2 (CH 2). Turning the dial to the right increases the volume and turning it to the left decreases it.
EQUALIZER HIGH CH 2
18
Equalizer high band for channel 2 (CH 2). When turned to the left, levels are lowered, when turned to the right, they are raised. In the centre position
(resting point), the equalizer is inactive.
19 EQUALIZER LOW CH 2
Equalizer bass band for channel 2 (CH 2). When turned to the left, levels are lowered, when turned to the right, they are raised. In the centre position
(resting point), the equalizer is inactive.
20 LEVEL DFX CH 2
Controller for adding the signal from channel 2 (Effects Send) to the internal digital effects device (effect volume channel 2). The effect presets are
selected with the help of the rotary encoder DFX PRESETS Nº 31.
21 LED CH 3 / 4
When an audio signal is present at the input of channel 3 /4 (CH 3/4), the LED indicator lights up green; if the LED is red, the channel is operating in
the clipping range. To avoid distortion, reduce the volume level of the playback device (e.g. keyboard, mixer) or the level of the volume controller 22.
22 LINE IN LEVEL CH 3 / 4
Volume controller for channel 3 / 4 (CH 3 / 4). Turning the dial to the right increases the volume and turning it to the left decreases it.
23

AUX INPUT

Stereo input with 3.5 mm stereo jack socket for a playback device (e.g. MP3 Player). The input is in parallel to the line inputs 3 and 4. The volume is
adjusted using the volume controller of channel 3 / 4 LEVEL CH 3/4 on the playback device.
24 BLUETOOTH LED
array system is equipped with Bluetooth, meaning that audio files from another Bluetooth device (e.g. smartphone)
The mixer of the LD CURV 500 ®
can be played back on the LD CURV 500
with the internal Bluetooth unit, the blue Bluetooth LED flashes briefly twice every 3 seconds or so, while the pairing standby LED flashes approx.
every 0.5 second; if the Bluetooth LED is on permanently, then a Bluetooth connection is established and the track playback can be started. The
volume is adjusted using the volume controller of channel 3 / 4 LEVEL CH 3/4 on the playback device.
HOLD TO LINK
25
To pair and connect the internal Bluetooth device with a Bluetooth-enabled device, press and hold the HOLD to LINK button for approx. 3 seconds
until the Bluetooth LED (24) flashes (approx. 2 Hz), enable Bluetooth on your Bluetooth device and search for available devices on the user interface.
Select "LD CURV500 ® " and pair your Bluetooth device with the internal Bluetooth device. The playback can now start. To end the connection, press
and hold the HOLD to LINK button again for approx. 3 seconds.
8
speakers (maximum distance between two devices about 10 metres). If no Bluetooth device is connected
®
